LPOD C-/Ku-Band Outdoor Amplifier / Block Up Converter (BUC)

Introduction

1.4.7

Block Up Converter (BUC) Input

The LPOD translates an L-Band input carrier to the desired output frequency (C-, X-, or Ku-

Band). LO frequencies are as follows:

BUC C, X, Ku, Ka LO Frequencies

Band

C-Band

X-Band

Ku-Band-W

Unlike most BUCs, no DC bias voltage should be provided on the center conductor of the L-Band

coax. In addition, the LPOD is available with an internal 10 MHz reference. As, such, no 10 MHz

reference is required on the center conductor of the L-Band coax. If a reference is provided on the

coax, the internal reference will detect and lock to it.

Frequency

LO Frequency

5850 to 6650 MHz

4900 MHz

7900 to 8400 MHz

6950 MHz

13.75 to 14.50 GHz

12.800 GHz

Inverting

1–7

Revision 0

MN-LPOD
