LPOD C-/Ku-Band Outdoor Amplifier / Block Up Converter (BUC)
Introduction
1.4.7

Block Up Converter (BUC) Input

The LPOD translates an L-Band input carrier to the desired output frequency (C-, X-, or Ku-
Band). LO frequencies are as follows:
BUC C, X, Ku LO Frequencies
Band
C-Band 5850 to 6650 MHz
X-Band 7900 to 8400 MHz
Ku-Band 14.00 to 14.50 GHz
Ku-Band-W 13.75 to 14.50 GHz
Unlike most BUCs, no DC bias voltage should be provided on the center conductor of the L-Band
coax. In addition, the LPOD is available with an internal 10 MHz reference. As, such, no 10 MHz
reference is required on the center conductor of the L-Band coax. If a reference is provided on the
coax, the internal reference will detect and lock to it.
Frequency LO Frequency
4900 MHz
6950 MHz
13.050 GHz
12.800 GHz
Inverting
No
No
No
No
1–7
Revision 3
MN-LPOD
