Comtech EF Data LPOD PS-1 Installation And Operation Manual page 66

LPOD C-/Ku-Band Outdoor Amplifier / Block Up Converter (BUC)
Remote Commands
Command
(Instruction
Parameter Type
Code and
Qualifier)
Retrieve Next 5 N/A
unread stored
Statistics
Phase 2 Release
Nunmber of N/A
Unread stored
Statistics
Phase 2 Release
Initialize Statistics ISP=
Pointer
Phase 2 Release
Arguments for
Description of arguments
Command or
(Note that all arguments are ASCII numeric codes: i.e.,
Response to
ASCII codes between 48 and 57)
Query
75 bytes Query only.
Unit returns the oldest 5 Stored Statistics entries which
have not yet been read over the remote control.
Reply format: {CR}Sub-body{CR}Sub-body{CR}Sub-
body{CR}Sub-body{CR}Sub-body, where:
Sub-body=
ddmmyyhhmmssaaa.abbb.bccc.cdd.ddefghhh.hiii.i
ddmmyy = day/month/year
hhmmss = hour:minute:second
aaa.a = Operating Temperature (I.E. +40.0)
bbb.b = Amp Temperature (I.E. +40.0)
ccc.c = RF Power output
dd.dd = Attenuation Setting
e = Amp On/Off
f = Mute On/Off
g = Online/Offline Status
hhh.h = LNB Current (mA)
iii.i = BUC Tuning Voltage
If there are less than 5 entries to be retrieved, the
remaining positions are padded with zeros.
If there are no new entries, the response is RNS*.
3 bytes Query only.
Unit returns the Number of stored Statistics, which
remain Unread in the form of xxx.
Example: NUS=126
None Command only.
Resets internal pointer to allow RNS? Queries to start
at the beginning of the stored statistics log.
Example: ISP=
Response to
(Target to controller)
ISP= (message ok)
ISP? (received ok, but
invalid arguments
found)
ISP* (message ok, but
not permitted in current
mode)
3–32
Query
(Instruction
Command
Code and
qualifier)
N/A RNS?
N/A NUS?
N/A
Revision 0
MN-LPOD
Response to
query
(Target to
controller)
RNS={CR}Sub-
body{CR}Sub-
body{CR}Sub-
body{CR}Sub-
body{CR}Sub-
body
(See description
for details of
arguments)
NUS=xxx
N/A
