Appendix A. Redundancy
A.4

Applicable Redundancy Commands

Remote commands applicable to redundancy operations are as follows:
Remote Command
RED
ESW
AFR
AOF
For detailed information on these commands, refer to Chapter 3. REMOTE COMMANDS.
A.5

Redundancy System Assembly Kits

The following figures and parts lists represent the 1:1 redundant switch kits:
•
Redundant 1:1 LPOD PS-1 C-Band Assembly Kit, P/N TBD
•
Redundant 1:1 LPOD PS-1 Ku-Band Assembly Kit, P/N TBD
•
Redundant 1:1 LPOD PS-2 C-Band Assembly Kit, P/N TBD
•
Redundant 1:1 LPOD PS-2 Ku-Band Assembly Kit, P/N TBD
Meaning
Redundancy Online/Offline
Enable Switch Mode
Auto Fault Recovery
Attenuation Offset
A–2
Functional Description
Reports the appropriate units online/offline
status. Also used to force a unit to go active
(online).
Puts the unit into redundancy or standalone
(manual) mode.
Sets the latching state of faults. Either they will
latch to the faulted state or they will recover
automatically.
Individual attenuation command, used to adjust
out small differences in power levels of different
amplifier
