LPOD C-/Ku-Band Outdoor Amplifier / Block Up Converter (BUC)
Remote Commands
Command
(Instruction
Parameter Type
Code and
Qualifier)
*Concise Utility N/A
Status
Software Image IMG=
IP Address IPA=
Gateway Address IPG=
Arguments for
Description of arguments
Command or
(Note that all arguments are ASCII numeric codes: i.e.,
Response to
ASCII codes between 48 and 57)
Query
15 bytes Query only.
Used to Query the Maintenance status of the unit,
response is comma delimited.
Example:
<1/CUS?'cr'>0001/CUS=aaaa;bbbbb;ccc;'cr''lf'
Where:
aaaa = Remote Unit Address
bbbbb = Remote Baud Rate
*ccc = Reference oscillator tuning voltage
DAC value
*Note: ccc is only present if a reference oscillator is
installed.
1 byte Command or Query.
Current Active software image, where:
1=Bulk Image # 1 currently active
2=Bulk Image # 2 currently active
Example: IMG=1 (which is Image #1 active)
18 bytes Command or Query.
Used to set the IP address and network prefix for the
10/100 BaseT Ethernet management port, in the
format:
xxx.xxx.xxx.xxx.yy, where:
xxx.xxx.xxx.xxx is the IP address, and
yy is the network prefix (8-30)
Example: 192.168.001.004.24
Default Value: 192.168.001.004.24
15 bytes Command or Query.
Used to set the Gateway IP addess for the 10/100
Base Tx Ethernet management port, in the format:
xxx.xxx.xxx.xxx, where:
xxx.xxx.xxx.xxx is the IP address
Example: IPG = 192.168.001.005
Default Value: 192.168.001.005
Response to
(Target to controller)
IPG= (message ok)
IPG? (received ok, but
invalid arguments
found)
IPG * (message ok, but
not permitted in current
mode
3–16
Query
(Instruction
Command
Code and
qualifier)
N/A CUS?
IMG= IMG?
IMG?
IMG*
IMG#
IPA= IPA?
IPA?
IPA*
IPA#
IPG?
Revision 0
MN-LPOD
Response to
query
(Target to
controller)
CUS=x....x
(See description
for details of
arguments)
IMG=x
(See description
of arguments)
IPA=
xx.xxx.xxx.xxx.yy
(See description
of arguments)
IPG =
xxx.xxx.xxx.xxx
