LPOD C-/Ku-Band Outdoor Amplifier / Block Up Converter (BUC)
Remote Commands
Command
(Instruction
Parameter Type
Code and
Qualifier)
Retrieve Alarm N/A
Status
Arguments for
Description of arguments
Command or
(Note that all arguments are ASCII numeric codes: i.e.,
Response to
ASCII codes between 48 and 57)
Query
168 bytes Query only.
Used to Query the Alarm status of the unit, where:
OK = no fault condition,
FT = faulted,
AL = alarm,
YS = Yes,
NO = No,
MS = masked.
Example:
<1/RAS?'cr'
>0001/RAS='cr'
P24V1=OK'cr'
P24V2=OK'cr'
LNBVT=OK'cr'
P13VT=OK'cr'
P10V1=OK'cr'
A10V1=OK'cr'
A10V2=OK'cr'
P7V8T=OK'cr'
P5V8T=OK'cr'
P2V5T=OK'cr'
P1V2T=OK'cr'
5.8V power supply
FANR1=OK'cr'
FANR2=OK'cr'
ATEMP=OK'cr'
SHTDN=OK'cr'
IICST=OK'cr' I2C bus status
FWPWR=OK'cr'
CHKSM=OK'cr'
FPGAD=OK'cr'
BUCLD=OK'cr'
REFLD=OK'cr'
LNBCS=OK'cr'
SWITC=OK'cr'
TRMST=YS'cr''lf' Terminal Status
Note: LNBVT, A10V1, A10V2, FANR1, FANR2,
BUCLD, REFLD, LNBCS, and SWITC will only appear
in the list if the appropriate model / options have been
selected / installed.
+24V power supply
+24V switch pwr supply
+13/18V LNB power supply
+13.5V power supply
+10V power supply
+10V1 RF supply
+10V2 RF supply
+7.8V power supply
+5.8V power supply
+2.5V power supply
+1.2V power supplyN5V8T=OK'cr'
Fan 1 speed
Fan 2 speed
Amplifier temperature
Over-temp shutdown
Forward power in dBm
Flash checksum
FPGA done status
BUC lock detect
Reference lock detect
LNB current status
Switch
3–20
Response to
(Instruction
Command
Code and
(Target to controller)
qualifier)
N/A
-
Revision 0
MN-LPOD
Query Response to
query
(Target to
controller)
RAS? RAS=x....x
(See description
for details of
arguments)
