LPOD C-/Ku-Band Outdoor Amplifier / Block Up Converter (BUC)
Remote Commands
*Note (where Parameter Type
should not be used for new implementations. There generally will be a different command elsewhere that encapsulates the marked functionality.
Command
(Instruction
Parameter Type
Code and
Qualifier)
Attenuation ATT=
Attenuation Offset AOF=
Phase 2 Release
Auto Fault AFR=
Recovery
is prefixed with *): While the underlying command will remain, the specific functionality will be obseleted, and
Arguments for
Description of arguments
Command or
(Note that all arguments are ASCII numeric codes: i.e.,
Response to
ASCII codes between 48 and 57)
Query
5 bytes Command or Query.
Valid attenuation level (00.00 to 20.00), in dB, in 0.25
dB steps as factory default.
Example: <1/ATT=12.25'cr'
>0001/ATT='cr''lf'
Default Value: 00.00
5 bytes Command or Query.
Valid attenuation level (00.00 to 20.00), in dB, in 0.25
dB steps as factory default. This value is not copied to
the offline unit in a redundant system, but will be
added to the attenuation value upon a switchover. This
provides a unit specific fine-tune to maintain power
levels appropriately in a redundant system.
Example: <1/AOF=12.25'cr'
>0001/AOF='cr''lf'
Default Value: 00.00
1 byte Command or Query.
The LPOD output will automatically be muted in the
event of detected fault. If auto fault recovery is
enabled, it will cause the output return to its pre-fault
mute condition if all faults are cleared. If disabled, the
output will remain muted even if all faults are cleared.
Example: <1/AFR=1'cr'
>0001/AFR='cr''lf'
Default Value: 1
Response to
Command
(Target to controller)
ATT= (message ok)
ATT? (Received ok, but
invalid arguments
found)
ATT* (message ok, but
not permitted in current
mode)
AOF= (message ok)
AOF? (Received ok, but
invalid arguments
found)
AOF* (message ok, but
not permitted in current
mode)
AFR = (message ok)
AFR? (received ok, but
invalid arguments
found)
AFR* (message ok, but
not permitted in current
mode)
3–8
Revision 0
MN-LPOD
Query Response to
(Instruction query
Code and (Target to
qualifier) controller)
ATT? ATT=xx.xx
(Same format as
command
arguments.)
AOF? AOF=xx.xx
(Same format as
command
arguments.)
AFR? AFR=x
(Same format as
command
arguments.)
