LPOD C-/Ku-Band Outdoor Amplifier / Block Up Converter (BUC)
Remote Commands
Command
(Instruction
Parameter Type
Code and
Qualifier)
Retrieve N/A
Configuration
Status
*Retrieve N/A
Equipment Type
Arguments for
Description of arguments
Command or
(Note that all arguments are ASCII numeric codes: i.e.,
Response to
ASCII codes between 48 and 57)
Query
45 bytes Query only.
Used to Query the configuration status of the unit
Example: RCS='cr'
ATT=12.75'cr'
AMP=1'cr'
MUT=1'cr'
ONL=1'cr'
ESW=1'cr'
AOF=00.00'cr'
AFR=1'cr'
XRF=N/A'cr''lf'
Where:
ATT= attenuation in dB
AMP= RF power amplifier state, 0=OFF, 1=ON
MUT=RF mute state, 0=un-muted, 1=muted
RED=Online status for redundancy
ESW=Redundancy state and mode,
states: 0=OFF, 1=ON Tx only, 2=ON Tx & Rx
AOF=Attenuator Offset in dB
AFR= auto fault recovery, 0=manual, 1=auto
XRF = External reference status, N/A = no external
reference, 05M for 5 MHz, and 10M for a 10 MHz
Note: XRF will always be N/A if the internal reference
oscillator option is not installed.
22 bytes Query only.
The unit returns a string indicating the Model Number
and the version of the MnC firmware installed in the
unit.
Example: <1/RET?'cr'
>0001/RET=CPA-300 VER: 1.0.3'cr''lf'
Response to
(Target to controller)
3–21
Query
(Instruction
Command
Code and
qualifier)
N/A RCS?
N/A RET?
Revision 0
MN-LPOD
Response to
query
(Target to
controller)
RCS=x....x
(See description
for details of
arguments)
RET=x....x
(See description
for details of
arguments)
