LPOD C-/Ku-Band Outdoor Amplifier / Block Up Converter (BUC)
Remote Commands
Command
(Instruction
Parameter Type
Code and
Qualifier)
Retrieve N/A
Maintenance
Status
Arguments for
Description of arguments
Command or
(Note that all arguments are ASCII numeric codes: i.e.,
Response to
ASCII codes between 48 and 57)
Query
Query only.
213 bytes, alpha-
Where:
numeric
P24V1 = +24V power supply
P24V2 = +24V switch power supply
*LNBVT = +13/18V LNB power supply
P13VT = +13.5V power supply
P10V1 = +10V1 power supply
A10V1 = 10V1 on RF Module
*A10V2 = 10V2 on RF Module
P7V8T = +7.8V power supply
P5V8T = +5.8V power supply
P2V5T = +2.5V power supply
P1V2T = +1.2V power supply
N5V8T = -5.8V power supply
FANR1 = Fan 1 speed in percent
*FANR2 = Fan 2 speed in percent
*BUCVT = BUC tuning voltage
FWPWR = Forward power in dBm
*REFVT = Reference osc. tuning voltage
*LNBCS = LNB current supply in mA
ATEMP = Heatsink temperature in Celcius
Example: <1/RMS?'cr'
>0001/RMS='cr'
P24V1=024.1'cr'
P24V2=024.1'cr'
LNBVT=018.2'cr'
P13VT=013.4'cr'
P10V1=010.1'cr'
A10V1=010.1'cr'
A10V2=010.1'cr'
P7V8T=007.8'cr'
P5V8T=005.8'cr'
P2V5T=002.5'cr'
P1V2T=001.2'cr'
N5V8T=-05.7'cr'
FANR1=100.0'cr'
FANR2=100.0'cr'
BUCVT=008.3'cr'
FWPWR=+53.2'cr'
REFVT=001.8'cr'
LNBCS=380.2'cr''If'
ATEMP=+40.0'cr'
*Note: LNBVT, FANR2, A10V2, BUCVT, REFVT and
LNBCS will appear if the appropriate options are installed;
otherwise, the values will report XXXX.
Response to
(Target to controller)
N/A
3–23
Query
(Instruction
Command
Code and
qualifier)
RMS?
Revision 0
MN-LPOD
Response to
query
(Target to
controller)
RMS=x....x
(See description
for details of
arguments)
