Comtech EF Data LPOD PS-1 Installation And Operation Manual page 46

LPOD C-/Ku-Band Outdoor Amplifier / Block Up Converter (BUC)
Remote Commands
Command
(Instruction
Parameter Type
Code and
Qualifier)
Software N/A
Revision
Calibrate LNB CLC=
Current
LNB Current LCS=
Source
Arguments for
Description of arguments
Command or
(Note that all arguments are ASCII numeric codes: i.e.,
Response to
ASCII codes between 48 and 57)
Query
34-37 bytes Query only.
Unit returns the value of the internal software revision
installed in the unit, in the form:
Boot:x.y.z Bulk1:x.y.z Bulk2:x.y.z
-or-
Boot:x.y.zz Bulk1:x.y.zz Bulk2:x.y.zz
none Command or Query.
The CLC command stores the value of the LNB
Current Supply (in mA) as a reference point. The LNB
current alarm point is then based on this point +/- the
LCW setting.
Note: this command will return a mode error if the LCS
output has not been enabled first.
Example: <1/CLC='cr'
>0001/CLC='cr''lf'
The CLC query will return the value that was stored
during the LNB current calibration.
Example: <1/CLC?'cr'
>0001/CLC=xxx.x
Where:
xxx.x is the calibrated LNB current value in mA.
1 byte Command or Query.
This command enables, or disables the LNB current
source. Note: LCS must be enabled before the LNB
current can be calibrated with the CLC command.
0 = Disable
1 = Enable
Example: <1/LCS=1'cr'
>0001/LCS='cr''lf'
Default Value: 0
Response to
(Target to controller)
CLC=(message ok)
CLC?(received ok, but
invalid arguments
found)
CLC*(message ok, but
not permitted in current
mode)
LCS=(message ok)
LCS?(received ok, but
invalid arguments
found)
LCS*(message ok, but
not permitted in current
mode)
3–12
Query
(Instruction
Command
Code and
qualifier)
N/A SWR?
CLC?
LCS?
Revision 0
MN-LPOD
Response to
query
(Target to
controller)
SWR=Boot:x.y.zz
Bulk1:x.y.zz
Bulk2:x.y.zz
(See description
of arguments)
CLC=xxx.x
(See description
of arguments)
LCS=x
(Same format as
command
arguments)
