Figure 2-1. Lpod Connectors - Comtech EF Data LPOD PS-1 Installation And Operation Manual

CONNECTIONS and OPERATION
2.1 Overview
This chapter summarizes the connectors provided for all necessary external connections between the
LPOD PS-1 (Figure 2-1 TOP) or PS-2 (Figure 2-1 BOTTOM) units and other equipment. Basic
operational information is also provided in Sect.2.3. For a detailed overview on the LPOD's
operability (via remote M&C commands), refer to Chapter 3. REMOTE CONTROL.
J10 J11
Modem Rx LNB
Power In
J3
J1
Tx In Power In
J1
L-Band In
COM1
J6
J3 J6 J10
COM1 Modem Rx

Figure 2-1. LPOD Connectors

(TOP: PS-1 model; BOTTOM: PS-2 model)
Chapter 2. SYSTEM
J11 J2 RF Out
LNB (Waveguide Intfc)
2–1
J2 RF Out
(Waveguide Intfc)
J9
Output Sample
