5.2 Software

42 GFK-2896
For public disclosure

5.2.1 Memory and I/O Address Mapping

The system memory and I/O address mapping is controlled by the G-Series SoC. Refer to
the appropriate datasheet for further details.

5.2.2 SMBus Slave Devices

The G-Series SoC provides two SMBus masters with attached on-board slave devices.
SMBus 1 is also routed to the carrier board.
Bus Device
0 CAT34TS02
1 I210
5.2.3 I 2

C Slave Devices

The FPGA hosts an I 2 C bus controller.
Device Function
AT24C32 Embedded EEPROM
AT24C32 User Data EEPROM
Temperature Sensor
SB-TSI

5.2.4 External Interrupts

All external interrupts are signaled through the serial IRQ or GPIO pins.
SMBus Devices
Function
SPD EEPROM
Temperature Sensor
Ethernet Controller
I 2 C Devices
7-bit Address
1010_000x
1010_001x
1001_100x
Mini COM Express Type 10 Module mCOM10-L1500
Address
1010_000x
0011_000x
Unused
