5 Configuration

There are no user-configurable
hardware options on the
mCOM10-L1500.

5.1 Hardware

Refer to the procedure, To
install the mCOM10-L1500
onto the carrier board.
Pin #
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
A13
A14
A15
A16
A17
A18
A19
A20
A21
A22
A23
A24
A25
A26
A27
A28
A29
Configuration
For public disclosure
The mCOM10-L1500 has been thoroughly tested, and is ready for use in your system. To
verify mCOM10-L1500 operation for the first time, only configure a minimal system. It is
not necessary to have disk drives, a Flash disk, or other accessories connected to perform
the mCOM10-L1500 UEFI boot sequence.

5.1.1 COM Express Type 10 Module Connectors

The COM Express connectors are used to interface the mCOM10-L1500 to the carrier
board. Connect the COM Express receptacle, located on the solder side of the module, to
the COM Express plug on the carrier board.
mCOM10-L1500 Connector Pin Assignments
Signal
GND
GBE0_MDI3–
GBE0_MDI3+
GBE0_LINK100#
GBE0_LINK1000#
GBE0_MDI2–
GBE0_MDI2+
GBE0_LINK#
GBE0_MDI1–
GBE0_MDI1+
GND
GBE0_MDI0–
GBE0_MDI0+
GBE0_CTREF
SUS_S3#
SATA0_TX+
SATA0_TX–
SUS_S4#
SATA0_RX+
SATA0_RX–
GND
USB_SSRX0–
USB_SSRX0+
SUS_S5#
USB_SSRX1–
USB_SSRX1+
BATLOW#
SATA_ACT#
AC/HDA_SYNC
Signal
Pin #
B1 GND
GBE0_ACT#
B2
LPC_FRAME#
B3
LPC_AD0
B4
LPC_AD1
B5
LPC_AD2
B6
LPC_AD3
B7
LPC_DRQ0#
B8
LPC_DRQ1#
B9
LPC_CLK
B10
B11 GND
B12 PWRBTN#
SMB_CK
B13
SMB_DAT
B14
SMB_ALERT#
B15
SATA1_TX+
B16
SATA1_TX–
B17
SUS_STAT#
B18
SATA1_RX+
B19
SATA1_RX–
B20
B21 GND
USB_SSTX0–
B22
USB_SSTX0+
B23
PWR_OK
B24
USB_SSTX1–
B25
USB_SSTX1+
B26
B27 WDT
AC/HDA_SDIN2
B28
AC/HDA_SDIN1
B29
