GE Mini COM Express 10 Hardware Reference Manual page 38

Signal Pin Type
THRM# I
CMOS
THRMTRIP# O
CMOS
Signal Pin Type
SMB_CK I/O OD
CMOS
SMB_DAT I/O OD
CMOS
SMB_ALERT# I
CMOS
Signal Pin Type
GPI0 I
CMOS
GPI1 I/O
CMOS
GPI2 O
CMOS
GPI3 O
CMOS
GPO0 O
CMOS
GPO1 O
CMOS
GPO2 I
CMOS
GPO3 I
CMOS
Signal Pin Type
TYPE10# PDS
Signal Pin Type
VCC_12V Power
VCC_5V_SBY Power
VCC_RTC Power
GND Power
38 GFK-2896
For public disclosure
Thermal Protection
Voltage Supply
3.3 V suspend
3.3 V
3.3 V
3.3 V
SMBus
Voltage Supply
3.3 V suspend
3.3 V
3.3 V suspend
3.3 V
3.3 V suspend
3.3 V
General-Purpose or SD I/O
Voltage Supply Description
3.3 V General-purpose input 0 or SDIO data 0
3.3 V
3.3 V General-purpose input 1 or SDIO data 1
3.3 V
3.3 V General-purpose input 2 or SDIO data 2
3.3 V
3.3 V General-purpose input 3 or SDIO data 3
3.3 V
3.3 V General-purpose output 0 or SDIO clock
3.3 V
3.3 V General-purpose output 1 or SDIO command/response
3.3 V
3.3 V General-purpose output 2 or SDIO write protect
3.3 V
3.3 V General-purpose output 3 or SDIO card detection
3.3 V
Module Type Definition
Voltage Supply Description
N/A Type 10 module indicator. Tied to GND.
Power and Ground
Voltage Supply Description
N/A Primary power input: +12 V nominal
N/A Standby power: +5.0 V nominal
N/A Real-time clock circuit power: +3.0 V nominal
N/A Ground
Description
Overtemperature indication from off-module sensor
CPU thermal shutdown
Description
Clock line
Data line
SMBus alert
Mini COM Express Type 10 Module mCOM10-L1500
