3 Installation and Startup
3.1 Required Materials
A carrier routes the I/O signals
of the mCOM10-L1500 to the
connectors.
Refer to chapter,
Specifications.
The keyboard is attached to the
carrier board.
Installation and Startup
For public disclosure
This chapter describes the installation of the mCOM10-L1500 module on a carrier board
and initial startup operations.
The following items are required to start the board in a standard configuration:
•
Carrier board and power supply
•
Keyboard and mouse
•
Video monitor
3.1.1 Carrier Board and Power Supply
You will need a carrier board wired with either an integrated or external regulated power
supply capable of providing stable low noise primary and standby sources. Verify that the
supply meets the voltage and total power requirements of the mCOM10-L1500.
Warning
3.1.2 Keyboard and Mouse
A compatible keyboard for initial system operation on the carrier board is required.
Depending on your application, this may be a standard keyboard, or one that uses
membrane switches for harsh environments.
3.1.3 Video Monitor
Any video monitor with an appropriate connection to a Digital Display Interface (DDI)
can be used initially for display output. Compatible interfaces are DisplayPort, DVI, and
HDMI. Access to the video signal is provided through the carrier board.
Verify that the power supply is turned OFF while
plugging or unplugging the board onto or from a
carrier card, respectively.
GFK-2896 Hardware Reference Manual 19
