of the antenna in the body co-ordinate frame (X positive forward, Z positive down).
11.8.5.3

Odometer Offset

The odometer offset is measured from the centre of the Spatial unit to the point at
which the vehicle's tyre makes contact with the road in the body co-ordinate frame (X
positive forward, Z positive down).
11.8.5.4

External Data Offset

These values are only required for speciality applications operating with external
sources of data. Please contact
with these values.
11.8.6

Baud Rates

When changing baud rates, some Microsoft Windows machines are unable to function
at the higher baud rates. It is recommended to test the baud rate first with the
permanent box unticked. This way, if it is not possible to communicate at the higher
baud rate, a power cycle can be used to revert to the previous baud rate.
support@advancednavigation.com.au
Illustration 44: Screenshot of
Spatial Manager baud rates
dialogue
Spatial Reference Manual
Page 82 of 158
Version 4.4
04/06/2019
for assistance
