13.9.37

External Pitot Pressure Packet

This packet is no longer supported. The External Air Data packet #68 should be used.
13.9.38

Wind Packet

This packet provides Spatial's current 2D wind velocity. These values are only valid
when external air data is provided to Spatial. This can be either through the External
Pitot Pressure Packet, the External Air Data Packet or when a pitot tube is interfaced to
one of the GPIO pins. When this packet is written to the device, it disables the wind
estimation filter and the wind values provided are used statically.
Packet ID
Length
Field Bytes
# Offset
1 0
2 4
3 8
Table 81: Wind packet
13.9.39

Heave Packet

Packet ID
Length
Field Bytes
# Offset
1 0
2 4
3 8
4 12
Table 82: Heave packet
13.9.40

Post Processing Packet

This packet is no longer supported. If you need an IMR file please contact Advanced
Navigation support for required settings.
Data Size
Type
fp32 4
fp32 4
fp32 4
Data Size
Type
fp32 4
fp32 4
fp32 4
fp32 4
Spatial Reference Manual
Wind Packet
Wind velocity north (m/s)
Wind velocity east (m/s)
Wind velocity standard deviation (m/s)
Heave Packet
Heave point 1 (m)
Heave point 2 (m)
Heave point 3 (m)
Heave point 4 (m)
Page 134 of 158
Version 4.4
04/06/2019
57
12
Description
58
16
Description
