13.9.10.1

Raw GNSS Status

Bit
0
1
2
3
4
5
6-15
Table 52: Raw GNSS status
13.9.11

Satellites Packet

Packet ID
Length
Field Bytes
# Offset
1 0
2 4
3 8
4 9
5 10
6 11
7 12
Table 53: Satellites packet
GNSS Fix Status, see section 13.9.1.3
Satellites Packet
Data Size
Type
fp32 4
fp32 4
u8 1
u8 1
u8 1
u8 1
u8 1
Spatial Reference Manual
Description
Doppler velocity valid
Time valid
External GNSS
Reserved (set to zero)
Description
HDOP
VDOP
GPS satellites
GLONASS satellites
BeiDou satellites
GALILEO satellites
SBAS satellites
Page 123 of 158
Version 4.4
04/06/2019
30
13
