Evaluation Kit

Spatial is supplied in an evaluation kit that contains everything required to get started
operating the system right away. The evaluation kit is supplied in a plastic carry case
to protect the equipment during shipping.
6.1

Evaluation Kit Contents

1. Spatial GNSS/INS
2. Rugged IP67 GPS/GLONASS/GALILEO/BeiDou GNSS antenna, part number
TW4721
3. Spatial connector to USB interface cable, part number A503-SDC20796, see
section 8.10
6.2

Quick Start

1. Position the GNSS antenna in a level orientation with a clear view of the sky.
2. Connect the coaxial antenna cable to Spatial.
3. Plug the interface cable into Spatial.
4. Plug the USB end of the interface cable into your computer.
5. Download the Spatial Manager software from the Spatial page of the Advanced
Navigation website. Java is required to run the software. Java is available from
http://www.java.com
6. Click the connect button in Spatial Manager.
7. The various windows in Spatial Manager can be used to view the real time data.
Illustration 7: Spatial Evaluation Kit
if not already installed.
