Part Numbers and Ordering Options

7.1

Evaluation Kit

Part Number
SPATIAL-EK
Table 4: Evaluation kit part numbers
7.2

Standalone Unit

Part Number
SPATIAL
SPATIAL-422
Table 5: Standalone unit part numbers
7.3

Accessories

Part Number
A503-SDC20796
TW4721
A503-SDC20740-2M
A503-SDC20753
CABLE-FTDI-DSUB-232
SUPPLY-24V
CAR12VPWR
Description
Spatial
Evaluation Kit
Description
Spatial Unit
Spatial Unit
(RS422)
Description
ODU plug to FTDI
USB cable
GNSS Antenna
ODU plug with
2m cable
(unterminated)
ODU to D9
connectors and
DC socket
FTDI USB to
RS232 Adaptor
24V DC Power
Supply
Car cigarette
lighter power
supply
Spatial Reference Manual
Page 28 of 158
Version 4.4
04/06/2019
Spatial evaluation kit
Includes items listed in section 6.1
Spatial Unit
L1 RTK supported
No cables or antennas included
Spatial Unit
L1 RTK supported
With optional RS422 interface
instead of standard RS232 interface
No cables or antennas included
Spatial ODU plug with 2m of cable to FTDI
RS232 to USB plug, see section 8.10
Magnetic mount L1 GNSS Antenna
(GPS/GLONASS/BeiDou/Galileo/SBAS)
Spatial ODU plug with 2m of unterminated
cable, see section 8.9
Spatial ODU plug with 2m of cable to
industry standard D9 connectors and DC
socket, see section 8.11
1 metre FTDI USB to RS232 Adaptor
100-240V AC Mains (IEC socket) to 24V
DC Power Supply (DC jack)
Car cigarette lighter to DC jack power
supply
