5.21.2 Pin assignments

5.21.2.1 Connection on printer side
Building Technologies
Fire Safety
Product version (ES) 01
3
2
1
Figure 102: Rear view ES01
Product version (ES) 02
3 2
+ –
1
Rear view ES02
1 Fastening clamps
2 Supply connection
3 Data line connection
Mounting and installation of the compact control panels
1
ES02: Serial interface settings
1
View from below
Event printer
RS232
RS232
TTL
TTL
