SITRANS F
Ultrasonic Flowmeters
SITRANS FS130 & FS230
Compact Operating Instructions
7ME372 (HART/Modbus)
12/2023
A5E38755607-AF
Introduction
Safety notes
Installing/mounting
Connecting
Commissioning
Service and maintenance
Technical specifications
Dimension drawings
Product documentation
and support
1
2
3
4
5
6
7
8
A

Advertisement

Table of Contents
loading

Related Manuals for Siemens SITRANS FS130

Summary of Contents for Siemens SITRANS FS130

  • Page 1 Introduction Safety notes Installing/mounting SITRANS F Connecting Ultrasonic Flowmeters SITRANS FS130 & FS230 Commissioning Service and maintenance Compact Operating Instructions Technical specifications Dimension drawings Product documentation and support 7ME372 (HART/Modbus) 12/2023 A5E38755607-AF...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Table Of Contents

    3.6.1.4 Turning the transmitter ...................... 26 3.6.1.5 Turning the local display..................... 27 3.6.2 Wall mount enclosure ......................28 3.6.3 Mounting the external DSL....................30 Installing sensors in Reflect mount ..................32 SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 4 Finishing the transmitter connection (wall mount) ............. 82 Commissioning ............................ 85 Basic Safety Notes ......................85 Local display ........................86 Access control........................88 Device startup ........................89 Service and maintenance ........................91 Basic safety notes....................... 91 SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 5 Industrial enclosure dimensions ..................113 Mounting bracket dimensions ..................114 External DSL dimensions ....................114 Product documentation and support ....................115 Product documentation ....................115 Technical support......................116 Index ..............................117 SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 6 Table of contents SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 7: Introduction

    SIMATIC PDM V9.1 Update 6 EDD: 1.05.00 or later FW: 1.05.00 for gas and liquid AMS Device Manager 14.0, HW: 002 and 003 14.1 Device revision 5 or later SITRANS DTM 4.2 Field communicator V3.8 SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 8: Designated Use

    Use the device to measure process medium in accordance with the information in the operating instructions. NOTICE Use in a domestic environment This Class A Group 1 equipment is intended for use in industrial areas. In a domestic environment this device may cause radio interference. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 9: Checking The Consignment

    Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure...

  • Page 10: Transportation And Storage

    The content reflects the technical status at the time of publishing. Siemens reserves the right to make technical changes in the course of further development.

  • Page 11: Safety Notes

    These include, for example: • National Electrical Code (NEC - NFPA 70) (USA) • Canadian Electrical Code (CEC) (Canada) Further provisions for hazardous area applications are for example: • IEC 60079-14 (international) • EN 60079-14 (EU) SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 12: Conformity With European Directives

    Note Operation under special ambient conditions We highly recommend that you contact your Siemens representative or our application department before you operate the device under special ambient conditions as can be encountered in nuclear power plants or when the device is used for research and development purposes.

  • Page 13: Use In Hazardous Areas

    • Observe the specifications for the electrical data on the certificate and/or in Technical specifications (Page 97). WARNING Dust layers above 5 mm Risk of explosion in hazardous areas. Device may overheat due to dust build up. • Remove dust layers in excess of 5 mm. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 14: Sensor Installation In Hazardous Areas

    Ex ia IIIC T70°C…T110°C Da Temperature code Varies by sensor and ambient temperature (see tables below) Dust Temperature class Tdust = Ta max + 10 °K (T70 °C for Ta = 60 °C, T110 °C for Ta = 100 °C) SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 15 Li (uH) Temperature code 7ME3950aLS0b T6 for Ta ≤ 60 °C T5 for Ta ≤ 100 °C Where, a = Approval: 5 (FM/CSA/ATEX/IECEX) b = Corrosion Protection: 0 (Standard) or 1 (Corrosion Resistant) SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 16 Requirements for safe installation • The sensors can be installed in Zone 0, Div. 1 as Intrinsically Safe. • Standard remote installation with FST030 because the connection is certified Intrinsically Safe. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 17: Installing/Mounting

    3. The maximum dust layer shall be no greater than 5 mm (T5 85°C). 4. The SITRANS FST030 industrial enclosure shall be bonded to the sensor (e.g. the SITRANS FSS200) that is powered via the "SSL interface", M12 connector (Pins 1 to 4). SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 18: External Dsl Specific Conditions Of Use

    Ensure that maximum permissible operating pressure of the device is not exceeded. Refer to the information on the nameplate and/or in Technical specifications (Page 97). SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 19: Installation Location Requirements

    The device can overheat or materials become brittle due to UV exposure. • Protect the device from direct sunlight. • Make sure that the maximum permissible ambient temperature is not exceeded. Refer to the information in Technical specifications (Page 97). SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 20: Fs130 System Overview (Internal Dsl)

    Path 2 - Upstream (2A) ④ ⑨ Path 1 - Downstream sensor cable (1B) Path 2 - Downstream (2B) ⑤ Sensors     Figure 3-1 Wall mount enclosure transmitter overview with FSS100 - FS130 SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 21: Fs130 System Overview (External Dsl)

    DSL. You can also connect the transmitter to other flow ultrasonic sensors. Wall mount transmitter overview with FS DSL11             Transmitter bottom view External DSL side view A External DSL side view B SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 22 DSL, up to 150 m ④ ⑩ Path 1-4 upstream (A) Protective earth ⑤ ⑪ Path 1-4 downstream (B) Ports for I/O, Communications ⑥ ⑫ Path 1-4 upstream (A) Ports for analog input or RTDs SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 23: Fs230 System Overview (Internal Dsl)

    Ports for I/O, Communications, RTDs ④ ⑧ Path 1 - downstream sensor cable (1B) Path 2 - upstream (2A) ⑨     Path 2 - downstream (2B) Figure 3-2 Wall mount transmitter overview (reflect mount) SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 24: Fs230 System Overview (External Dsl)

    Cable connection between FST030 Ports for I/O, Communications and external DSL, up to 150 m ④ ⑨ Path 1-4 upstream (A) Ports for analog input or RTDs ⑤ ⑩ Path 1-4 downstream (B) Protective earth SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 25: Installation Instructions

    1. Mount mounting bracket with cushion pad on pipe using fastening brackets/U-bolts and supplied pipe adaptor. Note U-bolts and other miscellaneous hardware are not supplied with the flowmeter. 2. Tighten nuts (torque: 10 Nm). SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 26: Mounting The Transmitter

    2. Loosen lock screw at transmitter pedestal using 5 mm Allen key. 3. Carefully rotate transmitter into desired position. 4. Firmly tighten lock screw (torque: 10 Nm). 5. Replace cap onto lock screw (torque: 10 Nm). SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 27: Turning The Local Display

    2. Remove display cover. 3. Use a small screwdriver or blade to loosen the three retaining clips within the transmitter. 4. Carefully pull out local display. 5. Turn display into desired position. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 28: Wall Mount Enclosure

    Care must be taken when opening the lid to avoid the lid falling. Note Mounting screws are not included You will need four screws, able to support at least 25 kg (55 lbs). SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 29 Mounting on pipe or in panel For mounting on pipe or on a panel see the installation instructions for the "Pipe/panel mount kit" which are provided with the optional pipe/panel mount kit. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 30: Mounting The External Dsl

    1. Remove mounting bracket from DSL. 2. Mount bracket on a wall using four screws. Figure 3-3 Mounting bracket on wall 3. Mount DSL on mounting bracket using four screws. Figure 3-4 Mounting DSL to mounting bracket SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 31 2. Mount bracket on a horizontal or a vertical pipe using ordinary hose clips or duct straps. Figure 3-5 Mounting bracket on vertical pipe Figure 3-6 Mounting bracket on horizontal pipe Figure 3-7 Mounting bracket on big horizontal pipe 3. Mount DSL on mounting bracket using four screws. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 32: Installing Sensors In Reflect Mount

    The spacing index provides the correct distance between the sensors based on the pipe size given. Before continuing refer to the Reflect mount installation diagram example below. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 33: Incorrect Mounting

    The device can be damaged, destroyed, or its functionality impaired through improper mounting. • Before installing ensure there is no visible damage to the device. • Mount the device using suitable tools. See operating instructions. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 34: Disassembly

    • If the device contains hazardous media, it must be emptied prior to disassembly. Make sure that no environmentally hazardous media are released. • Secure the remaining connections so that no damage can result if the process is started unintentionally. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 35: Connecting

    Damage to device through formation of condensation if the temperature difference between transportation or storage and the mounting location exceeds 20 °C (36 °F). • Before taking the device into operation, let the device adapt for several hours in the new environment. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 36 Exception: It may be permissible to omit connection of the equipotential bonding for devices with type of protection "Intrinsic safety Ex i". WARNING Unprotected cable ends Risk of explosion through unprotected cable ends in hazardous areas. • Protect unused cable ends in accordance with IEC/EN 60079-14. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 37 • Devices having the type of protection "Intrinsic safety Ex i" may also be connected in energized state in hazardous areas. WARNING Energized devices Risk of electric shock or explosion. When energized the device may be opened by qualified personnel only. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 38 • Ensure that the cover of the non-intrinsically safe circuits complies with degree of protection IP30 or higher according to IEC/EN 60529. • Separate connections of the non-intrinsically safe circuits in accordance with IEC/ EN 60079-14. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 39: Connecting The Sensor Cables (Internal Dsl Only)

    3. Place F-connector tool around cable and slide up to engage F-connector nut. 4. Push cable through the gland opening. Ensure that the center lead is aligned with connector port in the transmitter. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 40: Connecting The Sensor Cables To The Sensor

    2. Apply the supplied grease to the internal threads at the large end of the thread connector. ⑥ ③ 3. Observing the upstream and downstream orientation , connect upstream sensor cable ⑤ from the transmitter port (1A) to the sensor and make connection snug. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 41 Path 2 - Upstream (2A) ⑨     Path 2 - Downstream (2B) Figure 4-2 Wall mount enclosure with transmitter-to- sensor cable connections 5. Tighten all cable glands to obtain optimum sealing. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 42: Hi Precision Mount Fst030

    2. Apply Super Lube to the internal threads at the large end of the thread connector. ③ ④ 3. Observing the upstream and downstream orientation , connect upstream sensor cable from transmitter port (1A) and make connection snug. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 43 Path 1 - Upstream sensor cable to internal DSL port transmitter port (1B) (1A) ⑤     Hi Precision mounted sensors Figure 4-3 Hi Precision Reflect mount single enclosure wiring 5. Tighten all cable glands to obtain optimum sealing. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 44 2. Apply Super Lube to the internal threads at the large end of the thread connector. ③ ⑤ 3. Observing the upstream and downstream orientation , connect upstream sensor cable from transmitter port (1A) and make connection snug. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 45 Path 1 - Upstream sensor cable to internal DSL port (1A) Figure 4-4 HI Precision Direct mount Dual enclosure sensor wiring 5. Tighten all cable glands to obtain optimum sealing. 6. Refer to transmitter FST030 Operating Instructions to program transmitter. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 46: Connecting The External Dsl

    5. Finishing the DSL connection (Page 54) 4.5.1 Preparing for the external DSL connections 1. Remove lid from DSL 2. Remove F connector tool from DSL and use it to connect the sensor cables. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 47: Connecting The Sensor Cables

    4. Push cable through gland opening. Ensure that center lead is aligned with connector port in external DSL. 5. Tighten F-connector using tool until you meet mechanical stop. 6. Remove F-connector tool. 7. Mount and tighten cable gland. Repeat these steps for each sensor cable. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 48: Channel 5 And 6 Input Configuration

    For easier access unplug the terminal connector. After connecting the wires, plug the terminal connector back in. Note RTD shield grounding Make sure that the RTD cable shield is properly grounded. Consult the FSS200 Installation Manual on how to ground the RTD cable shield. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 49: Connecting Optional Devices

    Connecting 4 to 20 mA current input cable (passive) Note Connection of optional devices The DSL provides the option of connecting two additional devices to channels 5 and 6. Do not connect two devices to one channel. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 50 1. Remove cap and ferrule from cable gland and slide onto cable. ① ② 2. Remove one of the blind plugs ( ) and fit cable gland. 3. Push cable through gland opening. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 51 Wire to Isource - (green)     ⑦ ⑤ 5. Ground the RTD cable shield in the external DSL by sliding the crimp lug on wire onto ⑧ one of the installed strain reliefs screws SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 52: Connecting The Ssl Cable

    1. Connect DSL using the supplied 4-wire cable with M12 connectors to both the external DSL and the transmitter. Note Grounding The SSL cable shield is only mechanically connected to the grounding terminal (PE), when the M12 plug is correctly tightened. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 53 4. Push cable through gland opening. 5. Connect the four wires according to list below. Terminal connector Description Wire color +15 V DC Orange 0 V DC Yellow White Blue 6. Assemble and tighten cable gland. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 54: Finishing The Dsl Connection

    (bend cables downward) immediately before cable glands. Note Protection class The DSL is IP68 only if the lid is properly mounted and all M20 holes are closed with appropriate blind plugs or cable glands. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 55: Connecting Industrial Enclosure

    Current output/communication outputs (channel 1) 2. Remove lid lock screw for terminal connections lid. 3. Remove lid for terminal connections. A label showing the configuration is placed at the back of the terminal connections lid. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 56: Terminal Layout (Industrial Enclosure)

    Configuration of channels 1, 2, 3 and 4 Figure 4-6 Configuration label 4.6.1.1 Terminal layout (industrial enclosure) The following table shows: • Which cable with which terminal • Hardware and software configuration of the channels SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 57: Wiring Tool

    The wiring tool is located in the application terminal compartment. Figure 4-8 Wiring tool location 1. Insert wiring tool hook into receptor slot. 2. Press wiring tool wedge into top slot to spread clamp plates. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 58: Connecting The Ssl Cable (Industrial Enclosure)

    2. Remove one of the blind plugs and fit cable gland. 3. Remove cap and ferrule from cable gland and slide onto cable. 4. Push cable through open gland; anchor cable with clamp bar. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 59: Connecting Modbus

    1. Open enclosure lid. 2. Remove blind plug and fit cable gland. 3. Push cable through open gland and cable path. 4. Restore ferrule and tighten cap to lightly hold cable in place. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 60: Connecting Hart

    It is required to use shielded cables for the pure 4 to 20 mA current output. Note HART communication It is required by the FieldComm Group (FCG) to use shielded cables for the HART communication. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 61 2. Push cable through open gland and cable path. 3. Restore ferrule and tighten cap to lightly hold cable in place. 4. Signal cable screen is folded back over outer sheath and grounded beneath cable clamp. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 62 Signal output: < 500 Ω at 14 to 24 VDC (active), 14 to 30 VDC (passive) Relay output: 30 VAC/VDC, 100 mA Passive signal input: 15 to 30 VDC, 2 to 15 mA SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 63: Connecting Channels 2 To 4

    IO[3]+ (active) IO[3] (common) Functional Earth Functional Earth 4.6.6 Connecting the power supply 1. Open power supply terminal protection cover. 2. Remove cap and ferrule from cable gland and slide onto cable. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 64 DC connection Power: 100 to 240 V AC, 47 to 63 Hz Power: 20 to 27 V DC 6. Close and latch power supply terminal protection cover. 7. Tighten cable gland. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 65: Finishing The Transmitter Connection (Industrial Enclosure)

    Wind lid further by one quarter of a turn to seal on the O-ring. 7. Reinstate and tighten lid lock screw. 8. Ensure that moisture does not penetrate the inside of electronics enclosure. Bend cables downward immediately before cable glands. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 66: Connecting Wall Mount Enclosure

    Input/output connection (channels 2 to 4) ③ Modbus connection 2. Loosen spring screws on enclosure lid. 3. Open enclosure lid. A nameplate showing the configuration is placed on the inside of the transmitter enclosure lid. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 67: Terminal Layout (Wall Mount)

    Updates (to be filled in on firmware and hardware updates) ⑦ Configuration of channels 1 to 6 Figure 4-10 Example configuration label See also Input/output configuration (Page 77) 4.7.1.1 Terminal layout (wall mount) 24 V DC or 110/230 V AC SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 68: Connecting The Sensor Cables (Internal Dsl Only)

    Connecting the sensor cables (internal DSL only) Preparing for the connection 1. Loosen the four lid screws. 2. Open the lid. 3. Remove F-connector tool from wall mount enclosure. Figure 4-12 F-connector tool location SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 69: Connecting The Ssl Cable (Wall Mount Enclosure)

    7. Mount and tighten the cable gland. Repeat these steps for each sensor cable. 4.7.3 Connecting the SSL cable (wall mount enclosure) M12 connector version The SSL cable is provided with M12 style stainless steel plugs. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 70 Figure 4-13 Cable end 2. Remove cap and ferrule from cable gland and slide onto cable. ① 3. Remove blind plug and fit cable gland. Figure 4-14 Connection - SSL cable blind plugs SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 71 5. Remove cap and ferrule from cable gland and slide onto cable. 6. Push cable through open gland; anchor cable screen and wires with clamp bar. 7. Remove terminal block from DSL cassette. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 72 18.Close and secure DSL lid including lock screw. Turn the lid until you can feel the friction of the O-ring. From this point turn the lid ¼ turn to be tight. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 73: Connecting Modbus (Wall Mount)

    The terminal connector is detachable For easier access unplug the terminal connector. After connecting the wires, plug the terminal connector back in. – Wall mount transmitter Modbus ④ ⑤ 6. Tighten cable gland. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 74: Connecting Hart

    1. Open enclosure lid. 2. Remove blind plug and fit cable gland. 3. Push cable through open gland and cable path. 4. Restore ferrule and tighten cap to hold cable in place. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 75: Connecting Channels 2 To 4

    4.7.6 Connecting channels 2 to 4 Channel 2 is for output only, channels 3 to 4 can be ordered as either inputs/outputs or relays, see Preparing wall mount enclosure connections (Page 66) SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 76 The numbers in the graphics below refer to table Preparing wall mount enclosure connections (Page 66) If connected as input or output (channels 2 to 4) Active configuration Passive configuration ⑫ ⑬ ⑪ ⑫ Termination example for channel 3 SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 77: Input/Output Configuration

    Alarm item Active • NAMUR status signals Output Current output   Frequency output Passive Pulse output ChX- Status output ChXC • Alarm class ChX+ • Alarm item • NAMUR status signals Passive SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 78 • Density ChXa+ • Sensor temperature Active • Auxiliary temperature Current input Process values     Passive • Pressure ChX- • Medium temperature ChXC • Viscosity • Density ChX+   Passive SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 79: Connecting Channels 5 And 6 (Internal Dsl Only)

    2. Remove cap and ferrule from cable gland and slide onto cable. ④ ⑤ 3. Remove one of the blind plugs ( ) and fit cable gland. 4. Push cable through gland opening. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 80: Connecting The Power Supply (Wall Mount)

    • torque between 0.5 to 0.6 Nm • One wire per terminal connection 1. Open enclosure lid, unscrew power supply terminal protection cover screw, and remove protection cover. 2. Remove blind plug and fit cable gland. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 81 Connecting 4.7 Connecting wall mount enclosure 3. Push cable through open gland and cable path 4. Restore ferrule and tighten cap to lightly hold cable in place. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 82: Finishing The Transmitter Connection (Wall Mount)

    2. In case of Ex, remove all plastic blind plug caps and mount Ex rated cable glands or Ex rated blind plugs in unused cable entries. To ensure IP rating, remove caps and mount appropriate cable glands and blind plugs in unused cable entries. Firmly tighten cable glands. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 83 4.7 Connecting wall mount enclosure 3. Check individual wire installation by tugging firmly. 4. Close lid. 5. Tighten the four spring screws. 6. Ensure that moisture does not penetrate to inside of electronics enclosure. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 84 Connecting 4.7 Connecting wall mount enclosure SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 85: Commissioning

    • Check prior to commissioning that the cover, cover locks, and cable inlets are assembled in accordance with the directives. Exception: Devices having the type of protection "Intrinsic safety Ex i" may also be opened in energized state in hazardous areas. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 86: Local Display

    The device is commissioned/operated with the buttons on the local display. The buttons are actuated by touching the glass panel on the appropriate button. The graphical display above the buttons gives a menu-guided operation of the individual device SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 87 Automatic, display backlight goes off automatically 30 seconds after the last button press. Note Operation does not require opening of the device. This means that the high degree of protection of IP67 and safety in hazardous areas are guaranteed at all times. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 88: Access Control

    PIN codes can be changed in Security (5). Note Lost PIN code If the PIN code is lost, provide Siemens customer support with the transmitter serial number (see nameplate). Siemens customer support will provide a code to be entered in PIN recovery (5.4). Disable access level control If logged in as Expert you can Deactivate user PIN meaning that you will always be logged in as User and will not be prompted to enter the password.

  • Page 89: Device Startup

    Essential parameters should be considered before using the device for the first time. For any subsequent startup, after power-on, the device automatically starts in operation view. A transition screen showing first the Siemens logo and then the current firmware revision of the product is displayed while the first measurement is being processed.
  • Page 90 Commissioning 5.4 Device startup SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 91: Service And Maintenance

    Use of a computer in a hazardous area If the interface to the computer is used in the hazardous area, there is a risk of explosion. • Ensure that the atmosphere is explosion-free (hot work permit). SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 92: Cleaning

    WARNING Impermissible repair of explosion protected devices Risk of explosion in hazardous areas • Repair must be carried out by Siemens authorized personnel only. WARNING Maintenance during continued operation in a hazardous area There is a risk of explosion when carrying out repairs and maintenance on the device in a hazardous area.
  • Page 93 • Before you open the enclosure or remove enclosure parts, de-energize the device. • If maintenance measures in an energized state are necessary, observe the particular precautionary measures. Have maintenance work carried out by qualified personnel. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 94: On-Board Battery Replacement

    The on-board battery is used to maintain real time clock and should only be replaced with Panasonic BR1225A/BN. Siemens spare part number: A5E41372210 The battery is located in the transmitter cassette. The transmitter cassette location can be found in the exploded view.

  • Page 95: Disposal

    Observe the specific reg‐ ulations valid in your country. Further information about devices containing batteries can be found at: Information about battery / product return (WEEE) (https:// support.industry.siemens.com/cs/document/109479891/) SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 96 Service and maintenance 6.5 Disposal SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 97: Technical Specifications

    Technical specifications Note Device specifications Siemens makes every attempt to ensure the accuracy of these specifications but reserves the right to change them at any time. Power Table 7-1 Power supply Description Specification Supply voltage • 100 to 240 V AC, 47 to 63 Hz •...

  • Page 98: Modbus Interface

    Max. 24 V DC (active) 14 … 30 V DC (passive) Time constant (adjustable) 0 … 100 s Fault current NAMUR: Measurement range 4 … 20.8 mA 3.8 … 20.5 mA Minimum alarm 3.75 mA 3.5 mA Maximum alarm 22.6 mA 22.6 mA SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 99: Outputs

    0.0 to 100 s Fault current 4 - 20 NAMUR 4 - 20 US Measurement range (mA) 3.8 - 20.5 4.0 - 20.8 Lower fault current (mA) 3.75 Upper fault current (mA) 22.6 22.6 SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 100 Individual pair or overall screen is optional depending on user requirements. Voltage range Max. 24 V DC (active) 14 to 30 V DC (passive) User supplied cables must be suitable for 5°C above surrounding ambient temperature. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 101: Energy Limitation Parameters Fst030

          • Group IIC • 338 nF • 169.5 nF • 4.28 μF • Groups IIB, III • 1969 nF • 985 nF • 139 μF • Group IIA • 8199 nF • 1000 nF • 994 μF SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 102 2000 mW   • Group IIC • 338 nF • Groups IIB, III • 1969 nF   • Group IIC • 134 μH • Groups IIB, III • 675 μH   • Group IIC • 17.8 μH/Ω SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 103: Energy Limitation Parameters For External Dsl

    Energy limitation parameters for external DSL Table 7-16 Input parameters   SSL (power & signal) Analog input I/O 5 Analog input I/O 6 17.42 V DC 30 V DC 459 mA 100 mA 2.0 W 0.75 W 2.52 nF 0 nF 315 nH 105 nH SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 104: Construction

    No further reduction of external capacitance and inductance is required. Construction Table 7-19 Designated use Description Specification Measurement of process medium • Fluid Group 1 (suitable for dangerous fluids) • Aggregate state: Paste/light slurry, liquid and gas SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 105 Aluminum with corrosion-resistant coating Ingress protection IP66/67/NEMA 4X to EN/IEC 60529 (1 meter for 30 min) Mechanical load 18 to 1000 Hz random, 3.17 g RMS, in all directions, to EN/IEC 68-2-36 SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 106: Operating Conditions

    Technical specifications 7.9 Operating conditions Torques Table 7-24 Cable gland to enclosure installation torques (Siemens supplied, metric) Description Torque (Nm) Plastic blind plugs Plastic cable glands Brass cable glands/blind plugs Stainless steel cable glands/blind plugs Table 7-25 Wall mount enclosure installation torques...
  • Page 107 12.7 ... 10 m (0.5 ... 394") Wall Thickness Range 0.64 ... 76.2 mm (0.025 ... 3.0") Pipe material Any sonically conductive material (steel, plastic, aluminum, glass, ce‐ ment, ductile iron, copper) SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 108: Cables And Cable Entries

    Test voltage (wire/wire/screen rms 50 Hz 1 min) [V] = 700 Electrical data at reference temperature (20 °C) Table 7-32 Power supply cable recommendations Description Specification Square area [mm 1.3 (AWG 16) Max. length [m] 300 (AWG 16) SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 109: Certificates And Approvals

    Cable glands and fittings for use in Explosive Atmospheres 1. M20 to ½ NPT adaptors, M12 connector and plugs supplied by Siemens have been approved as part of the certification. 2. Cable glands shall be rated for a minimum ingress protection rating of IP54 and have an ambient temperature rating suitable for the installation with a safety factor of 5 °K above the...

  • Page 110: Approvals

    IECEx SIR 11.0150X Inmetro Ex db eb ia [ia Ga] IIC T6 Gb Ex tb [ia Da] IIIC T85°C Db • BRA 21.GE0013X Ambient temperature range Ta = -40°C to 60°C SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...
  • Page 111 Varies by sensor and ambient temperature (see Sensor installation in hazardous areas (Page 14)) Dust Temperature class Tdust = Ta max + 10 °K (T70 °C for Ta = 60 °C, T110 °C for Ta = 100 °C) SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 112: Sensorflash

    -40 to +85 °C (-40 to 185 °F) Storage: -40 to +100 °C (-40 to 212 °F) Note SensorFlash functions support Only the supplied 4 GB SD cards are supported for backup, restore, logging, and firmware update. SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 113: Dimension Drawings

    Dimension drawings Transmitter Figure 8-1 Transmitter dimensions in mm (") 8.1.1 Industrial enclosure dimensions Remote version 307 (12) 200 (7.8) Dimensions in mm SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 114: Mounting Bracket Dimensions

    Dimension drawings 8.3 External DSL dimensions Mounting bracket dimensions Industrial enclosure Dimensions in mm Weight: 4.8 kg (10.6 lbs) External DSL dimensions Figure 8-2 DSL dimensions in mm (") SITRANS FS130 & FS230 Compact Operating Instructions, 12/2023, A5E38755607-AF...

  • Page 115: Product Documentation And Support

    – "Download as html5, only PC": Open or save the manual in the HTML5 view on your PC You can also find manuals with the Mobile app at Industry Online Support (https:// support.industry.siemens.com/cs/ww/en/sc/2067). Download the app to your mobile device and scan the device QR code. Product documentation by serial number Using the PIA Life Cycle Portal, you can access the serial number-specific product information including technical specifications, spare parts, calibration data, or factory certificates.

  • Page 116: Technical Support

    (http:// www.siemens.com/automation/csi/service).   Service & support on the Internet In addition to our technical support, Siemens offers comprehensive online services at Service & Support (http://www.siemens.com/automation/service&support). Contact If you have further questions about the device, contact your local Siemens representative at Personal Contact (http://www.automation.siemens.com/partner).
