Mounting and installation of the compact control panels
5
Event printer
190 | 354
Building Technologies
Fire Safety
Mounting steps
Check the installation site carefully
Depending on the station type it is possible that the depth is insufficient for the
event printer. This must be checked especially if operating add-ons are used, as
the batteries are installed immediately behind the event printer.
If it is installed in the wrong place, this cannot be corrected and may under certain
circumstances affect the subsequent assembly of the station.
1. Using a knife, cut out the cover foil along the pre-cut opening.
2. Carefully loosen the pre-cut opening.
3. From the front side, insert the printer (1) into the opening (2) of the operating
unit.
4. Holding on to the printer, slide the fastening clamps (4) on both sides of the
printer from the rear into the guide slots (3) of the printer.
5. Press the clamps against the operating unit until you can hear them snap in
place and they hold the printer sufficiently well.
6. Connect the printer with the supplied cable kit according to the pin assignment.
