Siemens FS20 Mounting & Installation page 170

Mounting and installation of the compact control panels
5
Module bus cards
Element
Connection terminals
Connector
Degraded mode
Internal bus
170 | 354
Building Technologies
Fire Safety
Des. Function
X9 System supply connection
X11 Connection terminals for module bus card 1
X12 Connection terminals for module bus card 1
X21 Connection terminals for module bus card 2
X22 Connection terminals for module bus card 2
X31 Connection terminals for module bus card 3
X32 Connection terminals for module bus card 3
X41 Connection terminals for module bus card 4
X42 Connection terminals for module bus card 4
X51 Connection terminals for module bus card 5
X52 Connection terminals for module bus card 5
X15 Connector for degraded mode indicator [AT] of module bus card 1
X25 Connector for degraded mode indicator [AT] of module bus card 2
X35 Connector for degraded mode indicator [AT] of module bus card 3
X45 Connector for degraded mode indicator [AT] of module bus card 4
X55 Connector for degraded mode indicator [AT] of module bus card 5
X500 Connector for module bus output to other card cages
X501 Connector for module bus input
