How to Programme
NOTICE
For frequency converters with constant-speed
bypass
If an automatic bypass function starts the bypass at
persistent alarm conditions, disable the bypass's
automatic bypass function, if [2] Alarm or [3] Man. Reset
Alarm is selected as the dry-pump function.
22-61 Broken Belt Torque
Range: Function:
10 % [0 - 100 %] Sets the broken belt torque as a percentage
*
of the rated motor torque.
22-62 Broken Belt Delay
Range: Function:
10 s [0 - 600 Sets the time for which the broken-belt
s] conditions must be active before carrying out
the action selected in parameter 22-60 Broken
Belt Function.
22-75 Short Cycle Protection
Option: Function:
[0] Disabled Timer set in parameter 22-76 Interval between
*
Starts is disabled.
[1] Enabled Timer set in parameter 22-76 Interval between
Starts is enabled.
22-76 Interval between Starts
Range: Function:
Size [ par. 22-77 Sets the time desired as minimum
related - 3600 s] time between 2 starts. Any normal
*
start command (start/jog/freeze) is
disregarded until the timer has
expired.
22-77 Minimum Run Time
Range: Function:
NOTICE
0 s [ 0 - par.
*
22-76 s]
Does not work in cascade mode.
Sets the time desired as minimum run time
after a normal start command (start/jog/freeze).
Any normal stop command is disregarded until
the set time has expired. The timer starts
counting following a normal start command
(start/jog/freeze).
A coast (inverse) or an external interlock
command overrides the timer.
MG11F502
Operating Instructions

6.1.5 Main Menu Mode

Both the GLCP and NLCP provide access to the Main Menu
mode. Select the Main Menu mode by pressing [Main
Menu]. Illustration 6.18 shows the resulting readout, which
appears on the display of the GLCP.
Lines 2 to 5 on the display show a list of parameter groups
which can be selected by toggling [
Illustration 6.18 Display Example
Each parameter has a name and a number, which remain
the same regardless of the programming mode. In the
Main Menu mode, the parameters are divided into groups.
The first digit of the parameter number (from the left)
indicates the parameter group number.
All parameters can be changed in the Main Menu. The
configuration of the unit (parameter 1-00 Configuration
Mode) determines other parameters available for
programming. For example, selecting closed loop enables
more parameters related to closed-loop operation. Option
cards added to the unit enable more parameters
associated with the option device.

6.1.6 Parameter Selection

In the Main Menu mode, the parameters are divided into
groups. Press the navigation keys to select a parameter
group.
The following parameter groups are accessible:
Group no.
0-**
1-**
2-**
3-**
4-**
5-**
6-**
8-**
9-**
10-**
11-**
12-**
13-**
Danfoss A/S © 08/2014 All rights reserved.
▲
] and [
1107 RPM 3.84 A
Main menu
0 - ** Operation/Display
1 - ** Load/Motor
2 - ** Brakes
3 - ** Reference / Ramps
Parameter group
Operation/Display
Load/Motor
Brakes
References/Ramps
Limits/Warnings
Digital In/Out
Analog In/Out
Comm. and Options
Profibus
CAN Fieldbus
LonWorks
Ethernet
Smart Logic
▼
].
