Danfoss VLT HVAC Drive FC 102 Operating Instructions Manual page 51

Electrical Installation
Size/type [A]
P500-P1M0, 2.5–4.0
380–480 V
P710-P1M4,
525–690 V
P500-P1M0, 4.0–6.3
380–480 V
P710-P1M4,
525–690 V
P500-P1M0, 6.3 - 10
380–480 V
P710-P1M4,
525–690 V
P500-P1M0, 10–16
380–480 V
P710-P1M4,
525–690 V
Table 4.20 Manual Motor Controller Fuses
Enclosure size
F
Table 4.21 30 A Fuse-protected Terminal Fuse
Enclosure size
F
Table 4.22 Control Transformer Fuse
Enclosure size
F
Table 4.23 NAMUR Fuse
Enclosure size
F
Table 4.24 Safety Relay Coil Fuse with PILZ Relay
Enclosure size
E1/E2
E1/E2
F3
F3
F4 P800-P1M0 380-480 V & P1M0-P1M4 525-690 V
Table 4.25 Mains Disconnectors Enclosure Sizes E and F
MG11F502
Operating Instructions
Bussmann
Rating [V]
PN*
LPJ-6 SP 6 A, 600
or SPI
LPJ-10 SP 10 A, 600
or SPI
LPJ-10 SP 10 A, 600
or SPI
LPJ-15 SP 15 A, 600
or SPI
LPJ-15 SP 15 A, 600
or SPI
LPJ-20 SP 20 A, 600
or SPI
LPJ-25 SP 25 A, 600
or SPI
LPJ-20 SP 20 A, 600
or SPI
Bussmann PN*
LPJ-30 SP or SPI
Bussmann PN*
LPJ-6 SP or SPI
Bussmann PN*
GMC-800MA
Bussmann PN*
LP-CC-6
Power and voltage
P315 380-480 V & P450-P630 525-690 V
P355-P450 380-480 V
P500 380-480 V & P710-P800 525-690 V
P560-P710 380-480 V & P900 525-690 V
Danfoss A/S © 08/2014 All rights reserved.
Alternative fuses
Any listed Class J Dual Element, Time Delay, 6A
Any listed Class J Dual Element, Time Delay, 10 A
Any listed Class J Dual Element, Time Delay, 10 A
Any listed Class J Dual Element, Time Delay, 15 A
Any listed Class J Dual Element, Time Delay, 15 A
Any listed Class J Dual Element, Time Delay, 20A
Any listed Class J Dual Element, Time Delay, 25 A
Any listed Class J Dual Element, Time Delay, 20 A
Rating
30 A, 600 V Any listed Class J Dual Element,
Rating
6 A, 600 V Any listed Class J Dual Element,
Rating
800 mA, 250 V
Rating
6 A, 600 V Any listed Class CC, 6 A
Type
ABB OT600U03
ABB OT800U03
Merlin Gerin NPJF36000S12AAYP
Merlin Gerin NRK36000S20AAYP
Merlin Gerin NRK36000S20AAYP
Alternative fuses
Time Delay, 30 A
Alternative fuses
Time Delay, 6 A
Alternative fuses
49
4 4
