How to Operate the Frequenc...
Illustration 5.6 Indicator Lights
5 5
GLCP keys
Menu keys
The menu keys are divided into functions. The keys below
the display and indicator lights are used for parameter set-
up, including selection of display indication during normal
operation.
Status
Illustration 5.7 Menu Keys
[Status]
[Status] indicates the status of the frequency converter
and/or the motor. 3 different readouts can be selected by
pressing the [Status] key:
•
5-line readouts
•
4-line readouts
•
smart logic control
Press [Status] to select the display mode or for changing
back to Display mode from either Quick Menu mode, Main
Menu mode or Alarm mode. Also press [Status] to toggle
single or double readout mode.
[Quick Menu]
[Quick Menu] allows quick set-up of the frequency
converter. The most common HVAC functions can be
programmed here.
The Quick Menu consists of
•
My personal menu
•
Quick set-up
•
Function set-up
•
Changes made
•
Loggings
The Function Set-up provides quick and easy access to all
parameters required for most HVAC applications including:
64
Operating Instructions
On
Warn.
Alarm
Quick Main
Menu Menu
Danfoss A/S © 08/2014 All rights reserved.
•
Most VAV and CAV supply and return fans.
•
Cooling tower fans.
•
Primary, secondary and condenser water pumps.
•
Other pump, fan and compressor applications.
Among other features, it also includes parameters for
selecting which variables to display in the LCP, digital
preset speeds, scaling of analog references, closed loop
single-zone and multi-zone applications, and specific
functions related to fans, pumps and compressors.
The Quick Menu parameters can be accessed immediately
unless a password has been created via 0-60 Main Menu
Password, 0-61 Access to Main Menu w/o Password,
0-65 Personal Menu Password or 0-66 Access to Personal
Menu w/o Password.
It is possible to switch directly between Quick Menu mode
and Main Menu mode.
[Main Menu]
[Main Menu] is used for programming all parameters. The
Alarm
main menu parameters can be accessed immediately
Log
unless a password has been created via 0-60 Main Menu
Password, 0-61 Access to Main Menu w/o Password,
0-65 Personal Menu Password, or 0-66 Access to Personal
Menu w/o Password. For most HVAC applications, it is not
necessary to access the main menu parameters. Instead,
the Quick Menu, Quick Set-up and Function Set-up provide
the simplest and quickest access to the most required
parameters.
It is possible to switch directly between Main Menu mode
and Quick Menu mode.
Parameter shortcut can be carried out by pressing [Main
Menu] for 3 s. The parameter shortcut allows direct access
to any parameter.
[Alarm Log]
[Alarm Log] displays an alarm list of the 10 most recent
alarms (numbered A1-A10). To obtain more details about
an alarm, press the navigation keys to manoeuvre to the
alarm number and press [OK]. Information is displayed
about the condition of the frequency converter before it
enters the alarm mode.
The [Alarm Log] key on the LCP allows access to both
alarm log and maintenance log.
[Back]
[Back] reverts to the previous step or layer in the
navigation structure.
Illustration 5.8 Back Key
