Electrical Installation
1) 24 V DC, 5 A
T1 output taps
Temp switch
106 104 105
2) Manual motor starters
3) 30 A fuse-protected power terminals
4) Mains
R S T
L1 L2 L3
Illustration 4.6 Rectifier Cabinet, Enclosure Types F1, F2, F3 and F4
MG11F502
Operating Instructions
C J3
FUSE ONNECT
6
1
2
CH22 CH22 CH22 CH22 CH22 CH22
CTI25MB CTI25MB
8
10
3
4
FASTENER TORQUE: M10 19Nm (14 FT -LB)
+DC 89
5
5) Load sharing
-DC +DC
88 89
6) Control transformer fuses (2 or 4 pieces) (see Table 4.22 for part numbers)
7) SMPS fuse (see Table 4.18 for part numbers)
8) Manual motor controller fuses (3 or 6 pieces) (see Table 4.20 for part numbers)
9) Mains fuses, enclosure types F1 and F2 (3 pieces) (see Table 4.12 to Table 4.16 for
part numbers)
10) 30 Amp fuse-protected power fuses
