How to Programme
0-01 Language
Option: Function:
[46] Magyar Part of language package 3
[47] Czech Part of language package 3
[48] Polski Part of language package 4
[49] Russian Part of language package 3
[50] Thai Part of language package 2
[51] Bahasa Part of language package 2
Indonesia
[52] Hrvatski Part of language package 3
1-20 Motor Power [kW]
Range: Function:
Size [ 0.09 - Enter the nominal motor power in kW
related 3000.00 according to the motor nameplate data.
*
kW] The default value corresponds to the
nominal rated output of the unit.
Depending on the selections made in
0-03 Regional Settings, either
parameter 1-20 Motor Power [kW] or
parameter 1-21 Motor Power [HP] is made
invisible.
1-21 Motor Power [HP]
Range: Function:
Size [ 0.09 - Enter the nominal motor power in hp
related 3000.00 according to the motor nameplate data.
*
hp] The default value corresponds to the
nominal rated output of the unit.
Depending on the selections made in
0-03 Regional Settings, either
parameter 1-20 Motor Power [kW] or
parameter 1-21 Motor Power [HP] is made
invisible.
1-22 Motor Voltage
Range: Function:
Size [ 10 - Enter the nominal motor voltage
related 1000 V] according to the motor nameplate
*
data. The default value corresponds to
the nominal rated output of the
frequency converter.
1-23 Motor Frequency
Range: Function:
Size [20 - Select the motor frequency value from the
related 1000 motor nameplate data. For 87 Hz operation
*
Hz] with 230/400 V motors, set the nameplate
data for 230 V/50 Hz. Adapt
parameter 4-13 Motor Speed High Limit [RPM]
and 3-03 Maximum Reference to the 87 Hz
application.
MG11F502
Operating Instructions
1-24 Motor Current
Range:
Size
related
*
1-25 Motor Nominal Speed
Range:
Size related
1-28 Motor Rotation Check
Option:
[0] Off
*
[1] Enabled Motor rotation check is enabled.
WARNING
Remove mains power before disconnecting motor phase
cables.
NOTICE
Once the motor rotation check is enabled the display
shows: Note! Motor may run in wrong direction.
Pressing [OK], [Back] or [Cancel] dismisses the message
and displays a new message: "Press [Hand On] to start
the motor. Press [Cancel] to abort". Pressing [Hand On]
starts the motor at 5 Hz in forward direction and the
display shows: "Motor is running. Check if motor rotation
direction is correct. Press [Off] to stop the motor".
Pressing [Off] stops the motor and resets
parameter 1-28 Motor Rotation Check. If motor rotation
direction is incorrect, interchange 2 motor phase cables.
3-11 Jog Speed [Hz]
Range:
Size
related
*
Danfoss A/S © 08/2014 All rights reserved.
Function:
[ 0.10 - Enter the nominal motor current
10000.00 A] value from the motor nameplate
data. This data is used for
calculating motor torque, thermal
motor protection etc.
Function:
[100 - 60000 Enter the nominal motor speed
*
RPM] value from the motor nameplate
data. This data is used for
calculating automatic motor
compensations.
Function:
Following installation and connection of the
motor, this function allows the correct motor
rotation direction to be verified. Enabling this
function overrides any bus commands or digital
inputs, except external interlock and Safe Torque
Off (STO) (if included).
Motor rotation check is not active.
Function:
[ 0 - par. The jog speed is a fixed output speed
4-14 Hz] at which the frequency converter is
running when the jog function is
activated.
See also 3-80 Jog Ramp Time.
