How to Programme
Example of using the Quick Set-up
To set the ramp-down time to 100 s, follow this procedure:
1. Select Quick Set-up. Parameter 0-01 Language in
Quick Set-up appears.
2.
Press [
Ramp Down Time appears with the default setting
of 20 s.
3. Press [OK].
4.
Press [
comma.
5.
Change 0 to 1 by pressing [
6.
Press [
6 6
7.
Change 2 to 0 by pressing [
8. Press [OK].
The new ramp-down time is now set to 100 s.
Illustration 6.1 Quick Menu View
Access the 18 most important set-up parameters of the
frequency converter via Quick Set-up. After programming,
the frequency converter is ready for operation. The 18
Quick Set-up parameters are shown in Table 6.2.
Parameter
Parameter 0-01 Language
Parameter 1-20 Motor Power [kW]
Parameter 1-21 Motor Power [HP]
Parameter 1-22 Motor Voltage
Parameter 1-23 Motor Frequency
Parameter 1-24 Motor Current
Parameter 1-25 Motor Nominal Speed
Parameter 1-28 Motor Rotation Check
Parameter 3-41 Ramp 1 Ramp Up Time
Parameter 3-42 Ramp 1 Ramp Down Time
Parameter 4-11 Motor Speed Low Limit [RPM]
Parameter 4-12 Motor Speed Low Limit [Hz]
Parameter 4-13 Motor Speed High Limit [RPM]
Parameter 4-14 Motor Speed High Limit [Hz]
3-19 Jog Speed [RPM]
Parameter 3-11 Jog Speed [Hz]
5-12 Terminal 27 Digital Input
Parameter 5-40 Function Relay
Table 6.2 Quick Set-up Parameters
1) The information shown in the display depends on the selections
made in 0-02 Motor Speed Unit and 0-03 Regional Settings. The
74
Operating Instructions
▼
] repeatedly until parameter 3-42 Ramp 1
◀
] to highlight the third digit before the
▲
].
▶
] to highlight the digit 2.
▼
].
40.0% 4.84 A
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
1)
1)
1)
1)
2)
Danfoss A/S © 08/2014 All rights reserved.
default settings of 0-02 Motor Speed Unit and 0-03 Regional Settings
depend on which region of the world the frequency converter is
supplied to but can be reprogrammed as required.
2) Parameter 5-40 Function Relay is an array. Select between [0]
Relay1 or [1] Relay2. Standard setting is [0] Relay1 with the default
option [9] Alarm.
For detailed information about settings and programming,
see the VLT
NOTICE
If [0] No Operation is selected in 5-12 Terminal 27 Digital
Input, no connection to +24 V on terminal 27 is
necessary to enable start.
If [2] Coast Inverse (factory default value) is selected in
5-12 Terminal 27 Digital Input, a connection to +24 V is
necessary to enable start.
0-01 Language
Option:
1(1)
[0] English
*
[1] Deutsch
[2] Francais
[3] Dansk
[4] Spanish
[5] Italiano
[Units]
[6] Svenska
[kW]
[Hp]
[7] Nederlands
[V]
[10] Chinese
[Hz]
[A]
[20] Suomi
[RPM]
[22] English US
[Hz]
[s]
[27] Greek
[s]
[28] Bras.port
[RPM]
[Hz]
[36] Slovenian
[RPM]
[39] Korean
[Hz]
[RPM]
[40] Japanese
[Hz]
[41] Turkish
[42] Trad.Chinese
[43] Bulgarian
[44] Srpski
[45] Romanian
®
HVAC Drive FC 102 Programming Guide.
Function:
Defines display language. The frequency
converter is delivered with 4 different
language packages. English and German
are included in all packages. English
cannot be erased or manipulated.
Part of language packages 1–4
Part of language packages 1–4
Part of language package 1
Part of language package 1
Part of language package 1
Part of language package 1
Part of language package 1
Part of language package 1
Part of language package 2
Part of language package 1
Part of language package 4
Part of language package 4
Part of language package 4
Part of language package 3
Part of language package 2
Part of language package 2
Part of language package 4
Part of language package 2
Part of language package 3
Part of language package 3
Part of language package 3
MG11F502
