How to Programme
Group
Title
25-**
Cascade Controller
26-**
Analog I/O Option MCB
109
Table 6.1 Parameter Groups
Parameter descriptions and selections are displayed on the
graphic (GLCP) or numeric (NLCP) display. (See relevant
section for details.) Access the parameters by pressing
[Quick Menu] or [Main Menu] on the LCP. The Quick Menu
is used primarily for commissioning the unit at start-up by
providing the parameters necessary to start operation. The
Main Menu provides access to all parameters for detailed
application programming.
All digital input/output and analog input/output terminals
are multifunctional. All terminals have factory default
functions suitable for most HVAC applications but if other
special functions are required, they must be programmed
as explained in parameter group 5-** Digital In/out or 6-**
Analog In/out.
6.1.2 Quick Menu Mode
Parameter data
The graphical display (GLCP) provides access to all
parameters listed in the Quick Menu. The numeric display
(NLCP) only provides access to the Quick Set-up
parameters. To set parameters pressing [Quick Menu] -
enter or change parameter data or settings in accordance
with the following procedure:
1.
Press [Quick Menu].
▲
▼
2.
Press [
] or [
] to find the parameter to change.
3.
Press [OK].
▲
▼
4.
Press [
] or [
] to select the correct parameter
setting.
5.
Press [OK].
6.
To move to a different digit within a parameter
◀
setting, use the [
] and [
7.
Highlighted area indicates digit selected for
change.
8.
Press [Cancel] to disregard change, or press [OK]
to accept change and enter the new setting.
Example of changing parameter data
Assume parameter 22-60 Broken Belt Function is set to [0]
Off. To monitor the fan-belt condition, non-broken or
broken, follow this procedure:
MG11F502
Operating Instructions
Function
Parameters used to configure and monitor the built-in pump cascade controller (typically used
for pump booster sets).
Parameters used to configure the analog I/O option (MCB 109) including:
•
Definition of the analog input types (for example, voltage, Pt1000 or Ni1000).
•
Scaling and definition of the analog output functions and scaling.
▶
].
Danfoss A/S © 08/2014 All rights reserved.
1.
Press [Quick Menu].
▼
2.
Press [
] to select Function Set-ups.
3.
Press [OK].
▼
4.
Press [
] to select Application Settings .
5.
Press [OK].
6.
Press [OK] again for Fan Functions.
7.
Press [OK] to select Broken Belt Function.
▼
8.
Press [
], to select [2] Trip.
If a broken fan-belt is detected, the frequency converter
trips.
Select Q1 My Personal Menu to display personal
parameters
For example, an AHU or pump OEM may have pre-
programmed personal parameters to be in My Personal
Menu during factory commissioning to make on-site
commissioning/fine-tuning simpler. These parameters are
selected in 0-25 My Personal Menu. Up to 20 different
parameters can be programmed in this menu.
Select Changes Made to obtain information about:
•
The last 10 changes. Press [
between the last 10 changed parameters.
•
The changes made since default setting.
Loggings
Loggings show information about the display line
readouts. The information is shown as graphs.
Only display parameters selected in 0-20 Display Line 1.1
Small and 0-24 Display Line 3 Large can be viewed. Up to
120 samples can be stored in the memory for later
reference.
Quick Set-up
Efficient parameter set-up for HVAC applications
The parameters can easily be set up for most HVAC
applications only by using the Quick Set-up.
After pressing [Quick Menu], the different options in the
Quick Menu are listed. See also Illustration 6.1 and Table 6.3
to Table 6.6.
6
▲
▼
] and [
] to scroll
73
6
