Danfoss VLT HVAC Drive FC 102 Operating Instructions Manual page 44

Electrical Installation
4 4
1) Pilz relay terminal
2) RCD or IRM terminal
3) Mains
R S
91 92
L1 L2
Illustration 4.9 Options Cabinet, Enclosure Types F3 and F4
42
4
2
3
T
93
L3
Danfoss A/S © 08/2014 All rights reserved.
Operating Instructions
1 6
4) Safety relay coil fuse with PILZ relay (see Table 4.24 for part
numbers)
5) Mains fuses, F3 and F4 (3 pieces) (see Table 4.12 to Table 4.16 for
part numbers)
6) Contactor relay coil (230 VAC). N/C and N/O Aux contacts
(customer supplied)
7) Circuit breaker shunt trip control terminals (230 V AC or 230 V DC)
7
5
MG11F502
