Mechanical Installation
3.3.3 Terminal Locations - E Enclosures
Terminal locations - E1
Consider the following terminal positions when designing the cable access.
492[19.4]
323[12.7]
B
195[7.7]
Illustration 3.17 IP21 (NEMA Type 1) and IP54 (NEMA Type 12) Enclosure Power Connection Positions
MG11F502
Operating Instructions
0[0.0]
Danfoss A/S © 08/2014 All rights reserved.
3
3
17
