Mechanical Installation
3 3
Illustration 3.27 Terminal Locations - Regen Terminals - F2 and
F4
Terminal locations - rectifier (F1, F2, F3 and F4)
6
1 Load Share Terminal (-)
2 Ground Bar
3 Load Share Terminal (+)
Illustration 3.28 Terminal Locations - Rectifier (Left Side, Front and Right Side View). The Gland Plate is 42 mm below .0 Level.
24
Operating Instructions
1
435.5 [17.15]
343.1 [13.51]
193.9 [7.64]
70.4 [2.77]
0.0 [0.00]
Danfoss A/S © 08/2014 All rights reserved.
DC '-'
1739.1
1203.2
1163.2
1694.1
DC '+'
1654.1
1098.1
2
CH22 CH22 CH22 CH22 CH22 CH22
CTI25MB CTI25MB
FASTENER TORQUE: M8 9.6 Nm (7 FT-LB) FASTENER TORQUE: M10 19 Nm (14 FT-LB)
R/L1 91 S/L2 92 T/L3 93
FASTENER TORQUE: M10 19 Nm (14 FT-LB) FASTENER TORQUE: M10 19 Nm (14 FT-LB)
DC 89 DC 89
3
5
LOAD SHARE LOCATION
DIM F1/F2
A 380.5 [14.98] 29.4 [1.16]
B 432.5 [17.03] 81.4 [3.20]
4
F3/F4
MG11F502
