6 How to Programme the Low Harmonic Drive

6.5.2 Digital In/Out 5-**

Par. Parameter description
No. #
5-0* Digital I/O mode
5-00 Digital I/O Mode
5-01 Terminal 27 Mode
5-02 Terminal 29 Mode
5-1* Digital Inputs
5-10 Terminal 18 Digital Input
5-11 Terminal 19 Digital Input
5-12 Terminal 27 Digital Input
5-13 Terminal 29 Digital Input
5-14 Terminal 32 Digital Input
5-15 Terminal 33 Digital Input
5-16 Terminal X30/2 Digital Input
5-17 Terminal X30/3 Digital Input
5-18 Terminal X30/4 Digital Input
5-19 Terminal 37 Safe Stop
5-20 Terminal X46/1 Digital Input
5-21 Terminal X46/3 Digital Input
5-22 Terminal X46/5 Digital Input
6
5-23 Terminal X46/7 Digital Input
5-24 Terminal X46/9 Digital Input
5-25 Terminal X46/11 Digital Input
5-26 Terminal X46/13 Digital Input
5-3* Digital Outputs
5-30 Terminal 27 Digital Output
5-31 Terminal 29 Digital Output
5-32 Term X30/6 Digi Out (MCB 101)
5-33 Term X30/7 Digi Out (MCB 101)
5-4* Relays
5-40 Function Relay
5-41 On Delay, Relay
5-42 Off Delay, Relay

6.5.3 Comm. and Options 8-**

Par. Parameter description
No. #
8-0* General Settings
8-01 Control Site
8-02 Control Word Source
8-03 Control Word Timeout Time
8-04 Control Word Timeout Function
8-05 End-of-Timeout Function
8-06 Reset Control Word Timeout
8-3* FC Port Settings
8-30 Protocol
8-31 Address
8-32 FC Port Baud Rate
8-35 Minimum Response Delay
8-36 Max Response Delay
8-37 Max Inter-Char Delay
8-5* Digital/Bus
8-53 Start Select
8-55 Set-up Select
146
Default value 4-set-up
[0] PNP All set-ups
[0] Input All set-ups
[0] Input All set-ups
[8] Start All set-ups
[0] No operation All set-ups
[0] No operation All set-ups
[0] No operation All set-ups
[90] AC Contactor All set-ups
[91] DC Contactor All set-ups
[0] No operation All set-ups
[0] No operation All set-ups
[0] No operation All set-ups
[1] Safe Stop Alarm 1 set-up
[0] No operation All set-ups
[0] No operation All set-ups
[0] No operation All set-ups
[0] No operation All set-ups
[0] No operation All set-ups
[0] No operation All set-ups
[0] No operation All set-ups
[0] No operation All set-ups
[0] No operation All set-ups
[0] No operation All set-ups
[0] No operation All set-ups
[0] No operation All set-ups
0.30 s All set-ups
0.30 s All set-ups
Default value 4-set-up
[0] Digital and ctrl.word All set-ups
null All set-ups
1.0 s 1 set-up
[0] Off 1 set-up
[1] Resume set-up 1 set-up
[0] Do not reset All set-ups
[1] FC MC 1 set-up
2 N/A 1 set-up
[2] 9600 Baud 1 set-up
10 ms All set-ups
5000 ms 1 set-up
25 ms 1 set-up
[3] Logic OR All set-ups
[3] Logic OR All set-ups
®
