6 How to Programme the Low Harmonic Drive
It is recommended to do the set-up in the order listed.
Illustration 6.1: Quick Menu view.
6
No Operation is selected in terminal 27 no connection to +24 V on terminal 27 is necessary to enable start.
If
Coast Inverse (factory default value) is selected in Terminal 27, a connection to +24V is necessary to enable start.
If
NB!
For detailed parameter descriptions, please see the following section on
6.1.3 Q1 My Personal Menu
Parameters defined by the user can be stored in Q1 My Personal Menu.
My Personal Menu to display only the parameters, which have been pre-selected and programmed as personal parameters. For example, a pump
Select
or equipment OEM may have pre-programmed these to be in My Personal Menu during factory commissioning to make on site commissioning / fine tuning
simpler.. These parameters are selected in par. 0-25
20-21 Setpoint 1
20-93 PID Proportional Gain
20-94 PID Integral Time
6.1.4 Q2 Quick Setup
The parameters in Q2 Quick Setup are the basic parameters which are always needed to set-up the frequency converter to operation.
Parameter number and name
0-01 Language
1-20 Motor Power
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
3-41 Ramp 1 Ramp Up Time
3-42 Ramp 1 Ramp Down Time
4-11 Motor Speed Low Limit
4-13 Motor Speed High Limit
1-29 Automatic Motor Adaptation (AMA)
82
Par.
0-01
1-20
1-22
1-23
1-24
1-25
3-41
3-42
4-11
4-13
1-29
Table 6.2: Quick Setup parameters. Please see section
Parameters - Explanations
Commonly Used Parameters - Explanations .
My Personal Menu . Up to 20 different parameters can be defined in this menu.
Q1 My Personal Menu
Q2 Quick Setup
Unit
kW
V
Hz
A
RPM
s
s
RPM
RPM
®
MG.20.T1.02 - VLT is a registered Danfoss trademark
VLT AQUA Low Harmonic Drive Operating In-
Designation
Language
Motor Power
Motor Voltage
Motor Frequency
Motor Current
Motor Nominal Speed
Ramp 1 Ramp up Time
Ramp 1 Ramp down Time
Motor Speed Low Limit
Motor Speed High Limit
Automatic Motor Adaptation (AMA)
structions
[Units]
[kW]
[V]
[Hz]
[A]
[RPM]
[s]
[s]
[RPM]
[RPM]
Commonly Used
