Danfoss VLT AQUA Operating Instructions Manual page 114

6 How to Programme the Low Harmonic Drive
22-31 Power Correction Factor
Range:
100 %* [1 - 400 %]
22-32 Low Speed [RPM]
Range:
Application [Application dependant]
dependent*
22-33 Low Speed [Hz]
Range:
Application [Application dependant]
6
dependent*
22-34 Low Speed Power [kW]
Range:
Application [Application dependant]
dependent*
22-35 Low Speed Power [HP]
Range:
Application [Application dependant]
dependent*
22-36 High Speed [RPM]
Range:
Application [Application dependant]
dependent*
22-37 High Speed [Hz]
Range:
Application [Application dependant]
dependent*
22-38 High Speed Power [kW]
Range:
Application [Application dependant]
dependent*
114
Function:
Make corrections to the calculated power at par. 22-30
If No Flow is detected, when it should not be detected, the setting should be decreased. However,
if No Flow is not detected, when it should be detected, the setting should be increased to above
100%.
Function:
Motor Speed Unit has been set for RPM (parameter not visible if Hz selected).
To be used if par. 0-02
Set used speed for the 50% level.
This function is used for storing values needed to tune No Flow Detection.
Function:
To be used if par. 0-02 Motor Speed Unit has been set for Hz (parameter not visible if RPM selected).
Set used speed for the 50% level.
The function is used for storing values needed to tune No Flow Detection.
Function:
To be used if par. 0-03 Regional Settings has been set for International (parameter not visible if
North America selected).
Set power consumption at 50% speed level.
This function is used for storing values needed to tune No Flow Detection.
Function:
Regional Settings has been set for North America (parameter not visible if
To be used if par. 0-03
International selected).
Set power consumption at 50% speed level.
This function is used for storing values needed to tune No Flow Detection.
Function:
Motor Speed Unit has been set for RPM (parameter not visible if Hz selected).
To be used if par. 0-02
Set used speed for the 85% level.
The function is used for storing values needed to tune No Flow Detection.
Function:
Motor Speed Unit has been set for Hz (parameter not visible if RPM selected).
To be used if par. 0-02
Set used speed for the 85% level.
The function is used for storing values needed to tune No Flow Detection.
Function:
Regional Settings has been set for International (parameter not visible if
To be used if par. 0-03
North America selected).
Set power consumption at 85% speed level.
This function is used for storing values needed to tune No Flow Detection.
®
MG.20.T1.02 - VLT is a registered Danfoss trademark
VLT AQUA Low Harmonic Drive Operating In-
No-Flow Power .
structions
