6 How to Programme the Low Harmonic Drive
[35] Set digital out D low
[36] Set digital out E low
[37] Set digital out F low
[38] Set digital out A high
[39] Set digital out B high
[40] Set digital out C high
[41] Set digital out D high
[42] Set digital out E high
[43] Set digital out F high
[60] Reset Counter A
[61] Reset Counter B
[80] Sleep Mode
23-04 Occurrence
Array [10]
6
Option:
[0] * All days
[1] Working days
[2] Non-working days
[3] Monday
[4] Tuesday
[5] Wednesday
[6] Thursday
[7] Friday
[8] Saturday
[9] Sunday
6.3.12 Water Application Functions, 29-**
The group contains parameters used for monitoring water / wastewater applications.
29-00 Pipe Fill Enable
Option:
[0] * Disabled
[1] Enabled
29-01 Pipe Fill Speed [RPM]
Range:
Speed Low [Speed Low Limit - Speed High Lim-
Limit* it]
29-02 Pipe Fill Speed [Hz]
Range:
Motor [Speed Low Limit - Speed High Lim-
Speed Low it]
Limit*
122
Function:
Select which day(s) the Timed Action applies to. Specify working/non-working days in
par. 0-81 Working Days , par. 0-82 Additional Working Days and par. 0-83 Additional Non-Working
Days .
Function:
Select Enabled to fill pipes at a user specified rate.
Select Enabled to fill pipes with a user specified rate.
Function:
Set the filling speed for filling horizontal pipe systems. The speed can be selected in Hz or RPM
depending on the choices made in par. 4-11 / par. 4-13 (RPM) or in par. 4-12 / par. 4-14 (Hz).
Function:
Set the filling speed for filling horizontal pipe systems. The speed can be selected in Hz or RPM
depending on the choices made in par. 4-11 / par. 4-13 (RPM) or in par. 4-12 / par. 4-14 (Hz).
®
