VLT AQUA Low Harmonic Drive Operating In-
structions
[43] Set digital out F high
[60] Reset Counter A
[61] Reset Counter B
[80] Sleep Mode
NB!
For choices [32] - [43], see also par. group 5-3*E-##,
23-02 OFF Time
Array [10]
Range:
Application [Application dependant]
dependent*
23-03 OFF Action
Array [10]
Option:
[0] * Disabled
[1] * No action
[2] Select set-up 1
[3] Select set-up 2
[4] Select set-up 3
[5] Select set-up 4
[10] Select preset ref 0
[11] Select preset ref 1
[12] Select preset ref 2
[13] Select preset ref 3
[14] Select preset ref 4
[15] Select preset ref 5
[16] Select preset ref 6
[17] Select preset ref 7
[18] Select ramp 1
[19] Select ramp 2
[22] Run
[23] Run reverse
[24] Stop
[26] DC Brake
[27] Coast
[32] Set digital out A low
[33] Set digital out B low
[34] Set digital out C low
Digital Outputs and 5-4*, Relays .
Function:
Sets the OFF time for the Timed Action.
NB!
The frequency converter has no back up of the clock function and the set date/
time will reset to default (2000-01-01 00:00) after a power down unless a Real
Time Clock module with back up is installed. In par. 0-79
to program for a Warning in case clock has not been set properly, e.g. after a
power down.
Function:
Select the action during OFF Time. See par. 13-52
tions.
®
MG.20.T1.02 - VLT is a registered Danfoss trademark
6 How to Programme the Low Harmonic Drive
SL Controller Action for descriptions of the op-
6
Clock Fault it is possible
