6 How to Programme the Low Harmonic Drive

6.4.8 Analog In/Out 6-**

Par. Parameter description
No. #
6-0* Analog I/O Mode
6-00 Live Zero Timeout Time
6-01 Live Zero Timeout Function
6-1* Analog Input 53
6-10 Terminal 53 Low Voltage
6-11 Terminal 53 High Voltage
6-12 Terminal 53 Low Current
6-13 Terminal 53 High Current
6-14 Terminal 53 Low Ref./Feedb. Value
6-15 Terminal 53 High Ref./Feedb. Value
6-16 Terminal 53 Filter Time Constant
6-17 Terminal 53 Live Zero
6-2* Analog Input 54
6-20 Terminal 54 Low Voltage
6-21 Terminal 54 High Voltage
6-22 Terminal 54 Low Current
6-23 Terminal 54 High Current
6-24 Terminal 54 Low Ref./Feedb. Value
6-25 Terminal 54 High Ref./Feedb. Value
6
6-26 Terminal 54 Filter Time Constant
6-27 Terminal 54 Live Zero
6-3* Analog Input X30/11
6-30 Terminal X30/11 Low Voltage
6-31 Terminal X30/11 High Voltage
6-34 Term. X30/11 Low Ref./Feedb. Value
6-35 Term. X30/11 High Ref./Feedb. Value
6-36 Term. X30/11 Filter Time Constant
6-37 Term. X30/11 Live Zero
6-4* Analog Input X30/12
6-40 Terminal X30/12 Low Voltage
6-41 Terminal X30/12 High Voltage
6-44 Term. X30/12 Low Ref./Feedb. Value
6-45 Term. X30/12 High Ref./Feedb. Value
6-46 Term. X30/12 Filter Time Constant
6-47 Term. X30/12 Live Zero
6-5* Analog Output 42
6-50 Terminal 42 Output
6-51 Terminal 42 Output Min Scale
6-52 Terminal 42 Output Max Scale
6-53 Terminal 42 Output Bus Control
6-54 Terminal 42 Output Timeout Preset
6-6* Analog Output X30/8
6-60 Terminal X30/8 Output
6-61 Terminal X30/8 Min. Scale
6-62 Terminal X30/8 Max. Scale
6-63 Terminal X30/8 Output Bus Control
6-64 Terminal X30/8 Output Timeout Preset
130
VLT AQUA Low Harmonic Drive Operating In-
Default value
10 s
[0] Off
0.07 V
10.00 V
4.00 mA
20.00 mA
0.000 N/A
SR
0.001 s
[1] Enabled
0.07 V
10.00 V
4.00 mA
20.00 mA
0.000 N/A
100.000 N/A
0.001 s
[1] Enabled
0.07 V
10.00 V
0.000 N/A
100.000 N/A
0.001 s
[1] Enabled
0.07 V
10.00 V
0.000 N/A
100.000 N/A
0.001 s
[1] Enabled
[100] Output freq. 0-100
0.00 %
100.00 %
0.00 %
0.00 %
[0] No operation
0.00 %
100.00 %
0.00 %
0.00 %
®
MG.20.T1.02 - VLT is a registered Danfoss trademark
4-set-up Change dur- Conver-
ing operation sion index
All set-ups TRUE 0
All set-ups TRUE -
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -5
All set-ups TRUE -5
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -5
All set-ups TRUE -5
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -2
1 set-up TRUE -2
All set-ups TRUE -
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -2
1 set-up TRUE -2
structions
Type
Uint8
Uint8
Int16
Int16
Int16
Int16
Int32
Int32
Uint16
Uint8
Int16
Int16
Int16
Int16
Int32
Int32
Uint16
Uint8
Int16
Int16
Int32
Int32
Uint16
Uint8
Int16
Int16
Int32
Int32
Uint16
Uint8
Uint8
Int16
Int16
N2
Uint16
Uint8
Int16
Int16
N2
Uint16
