Danfoss VLT AQUA Operating Instructions Manual page 96

6 How to Programme the Low Harmonic Drive
NB!
Full AMA should be run without filter only while reduced AMA should be run with filter.
See section: Application Examples > Automatic Motor Adaptation in the Design Guide.
6.3.4 3-0* Reference Limits
Parameters for setting the reference unit, limits and ranges.
3-02 Minimum Reference
Range:
Application [Application dependant]
dependent*
6
3-03 Maximum Reference
Range:
Application [Application dependant]
dependent*
3-10 Preset Reference
Array [8]
Range:
0.00 %* [-100.00 - 100.00 %]
96
Function:
Enter the Minimum Reference. The Minimum Reference is the lowest value obtainable by summing
all references. The Minimum Reference value and unit matches the configuration choice made in
Configuration Mode and par. 20-12 Reference/Feedback Unit , respectively.
par. 1-00
NB!
This parameter is used in open loop only.
Function:
Enter the maximum acceptable value for the remote reference. The Maximum Reference value and
unit matches the configuration choice made in par. 1-00
erence/Feedback Unit , respectively.
NB!
If operating with par. 1-00
par. 20-14 Maximum Reference/Feedb. must be used.
Function:
Enter up to eight different preset references (0-7) in this parameter, using array programming. The
preset reference is stated as a percentage of the value Ref
Maximum Reference/Feedb. ). When using preset references, select Pre-
closed loop see par. 20-14
set ref. bit 0 / 1 / 2 [16], [17] or [18] for the corresponding digital inputs in parameter group 5-1*
Digital Inputs.
®
MG.20.T1.02 - VLT is a registered Danfoss trademark
VLT AQUA Low Harmonic Drive Operating In-
Configuration Mode and par. 20-12 Ref-
Configuration Mode set for Closed Loop [3],
Maximum Reference , for
(par. 3-03
MAX
structions
