VLT AQUA Low Harmonic Drive Operating In-
structions
1
Illustration 4.30: Active Filter, frame size F17
1) Line
R S T
L1 L2 L3
3
2) Bus bars to rectifier section of drive
3) Fuse block
®
MG.20.T1.02 - VLT is a registered Danfoss trademark
4 How to Install
2
Section shown
↓
4
47
