Danfoss VLT AQUA Operating Instructions Manual page 106

6 How to Programme the Low Harmonic Drive
6-10 Terminal 53 Low Voltage
Range:
0.07 V* [Application dependant]
6-11 Terminal 53 High Voltage
Range:
10.00 V* [Application dependant]
6-14 Terminal 53 Low Ref./Feedb. Value
Range:
0.000 N/A* [-999999.999 - 999999.999 N/A]
6-15 Terminal 53 High Ref./Feedb. Value
6
Range:
Application [-999999.999 - 999999.999 N/A]
dependent*
6-20 Terminal 54 Low Voltage
Range:
0.07 V* [Application dependant]
6-21 Terminal 54 High Voltage
Range:
10.00 V* [Application dependant]
6-24 Terminal 54 Low Ref./Feedb. Value
Range:
0.000 N/A* [-999999.999 - 999999.999 N/A]
6-25 Terminal 54 High Ref./Feedb. Value
Range:
100.000 N/ [-999999.999 - 999999.999 N/A]
A*
6-50 Terminal 42 Output
Option:
[0] * No operation
[100] Output freq. 0-100
[101] Reference Min-Max
[102] Feedback +-200%
[103] Motor cur. 0-Imax
[104] Torque 0-Tlim
106
Function:
Enter the low voltage value. This analog input scaling value should correspond to the low reference/
Terminal 53 Low Ref./Feedb. Value .
feedback value set in par. 6-14
Function:
Enter the high voltage value. This analog input scaling value should correspond to the high refer-
ence/feedback value set in par. 6-15
Function:
Enter the analog input scaling value that corresponds to the low voltage/low current set in
par. 6-10 Terminal 53 Low Voltage and par. 6-12 Terminal 53 Low Current .
Function:
Enter the analog input scaling value that corresponds to the high voltage/high current value set in
Terminal 53 High Voltage and par. 6-13 Terminal 53 High Current .
par. 6-11
Function:
Enter the low voltage value. This analog input scaling value should correspond to the low reference/
Terminal 54 Low Ref./Feedb. Value .
feedback value, set in par. 6-24
Function:
Enter the high voltage value. This analog input scaling value should correspond to the high refer-
ence/feedback value set in par. 6-25
Function:
Enter the analog input scaling value that corresponds to the low voltage/low current value set in
par. 6-20 Terminal 54 Low Voltage and par. 6-22 Terminal 54 Low Current .
Function:
Enter the analog input scaling value that corresponds to the high voltage/high current value set in
par. 6-21 Terminal 54 High Voltage and par. 6-23 Terminal 54 High Current .
Function:
Select the function of Terminal 42 as an analog current output. A motor current of 20 mA corre-
sponds to I .
max
0 - 100 Hz, (0-20 mA)
Minimum reference - Maximum reference, (0-20 mA)
-200% to +200% of par. 20-14 Maximum Reference/Feedb. , (0-20 mA)
0 - Inverter Max. Current (par. 16-37
Torque Limit Motor Mode ), (0-20 mA)
0 - Torque limit (par. 4-16
®
MG.20.T1.02 - VLT is a registered Danfoss trademark
VLT AQUA Low Harmonic Drive Operating In-
Terminal 53 High Ref./Feedb. Value .
Terminal 54 High Ref./Feedb. Value .
Inv. Max. Current ), (0-20 mA)
structions
