VLT AQUA Low Harmonic Drive Operating In-
structions
Par. Parameter description
No. #
21-5* Ext. CL 3 Ref./Fb.
21-50 Ext. 3 Ref./Feedback Unit
21-51 Ext. 3 Minimum Reference
21-52 Ext. 3 Maximum Reference
21-53 Ext. 3 Reference Source
21-54 Ext. 3 Feedback Source
21-55 Ext. 3 Setpoint
21-57 Ext. 3 Reference [Unit]
21-58 Ext. 3 Feedback [Unit]
21-59 Ext. 3 Output [%]
21-6* Ext. CL 3 PID
21-60 Ext. 3 Normal/Inverse Control
21-61 Ext. 3 Proportional Gain
21-62 Ext. 3 Integral Time
21-63 Ext. 3 Differentation Time
21-64 Ext. 3 Dif. Gain Limit

6.4.19 Application Functions 22-**

Par. Parameter description
No. #
22-0* Miscellaneous
22-00 External Interlock Delay
22-2* No-Flow Detection
22-20 Low Power Auto Set-up
22-21 Low Power Detection
22-22 Low Speed Detection
22-23 No-Flow Function
22-24 No-Flow Delay
22-26 Dry Pump Function
22-27 Dry Pump Delay
22-28 No-Flow Low Speed [RPM]
22-29 No-Flow Low Speed [Hz]
22-3* No-Flow Power Tuning
22-30 No-Flow Power
22-31 Power Correction Factor
22-32 Low Speed [RPM]
22-33 Low Speed [Hz]
22-34 Low Speed Power [kW]
22-35 Low Speed Power [HP]
22-36 High Speed [RPM]
22-37 High Speed [Hz]
22-38 High Speed Power [kW]
22-39 High Speed Power [HP]
22-4* Sleep Mode
22-40 Minimum Run Time
22-41 Minimum Sleep Time
22-42 Wake-up Speed [RPM]
22-43 Wake-up Speed [Hz]
22-44 Wake-up Ref./FB Difference
22-45 Setpoint Boost
22-46 Maximum Boost Time
22-5* End of Curve
22-50 End of Curve Function
22-51 End of Curve Delay
22-6* Broken Belt Detection
22-60 Broken Belt Function
22-61 Broken Belt Torque
22-62 Broken Belt Delay
22-7* Short Cycle Protection
22-75 Short Cycle Protection
22-76 Interval between Starts
22-77 Minimum Run Time
Default value
[0]
0.000 ExtPID3Unit
100.000 ExtPID3Unit
[0] No function
[0] No function
0.000 ExtPID3Unit
0.000 ExtPID3Unit
0.000 ExtPID3Unit
0 %
[0] Normal
0.50 N/A
20.00 s
0.00 s
5.0 N/A
Default value
0 s
[0] Off
[0] Disabled
[0] Disabled
[0] Off
10 s
[0] Off
10 s
SR
SR
0.00 kW
100 %
SR
SR
SR
SR
SR
SR
SR
SR
60 s
30 s
SR
SR
10 %
0 %
60 s
[0] Off
10 s
[0] Off
10 %
10 s
[0] Disabled
start_to_start_min_on_time
(P2277)
0 s
®
MG.20.T1.02 - VLT is a registered Danfoss trademark
6 How to Programme the Low Harmonic Drive
4-set-up Change dur-
ing operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
4-set-up Change dur-
ing operation
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Conver- Type
sion index
- Uint8
-3 Int32
-3 Int32
- Uint8
- Uint8
-3 Int32
-3 Int32
-3 Int32
0 Int32
- Uint8
-2 Uint16
-2 Uint32
-2 Uint16
-1 Uint16
6
Conver- Type
sion index
0 Uint16
- Uint8
- Uint8
- Uint8
- Uint8
0 Uint16
- Uint8
0 Uint16
67 Uint16
-1 Uint16
1 Uint32
0 Uint16
67 Uint16
-1 Uint16
1 Uint32
-2 Uint32
67 Uint16
-1 Uint16
1 Uint32
-2 Uint32
0 Uint16
0 Uint16
67 Uint16
-1 Uint16
0 Int8
0 Int8
0 Uint16
- Uint8
0 Uint16
- Uint8
0 Uint8
0 Uint16
- Uint8
0 Uint16
0 Uint16
139
