6

Operation

6.1

Switching ON

6.2

Status LED

6-1
Operation
Install the device as described in the Installation chapter. Connect the power cable.
Switch the device ON. The mains switch and the connection for the power cable are
at the back of the device.
After the mains switch has been actuated the devices runs up automatically.
In run-up mode ( 3 Min.) the following items appear on the display:
• Speed of the turbo-molecular pump
• Fore-vacuum pressure
• State of emission
• Active filament
• A bar graph which shows the run-up progress
After the run-up has been completed, the Modul1000 is in „Standby" mode.
The LEDs show the operating mode of the device:
Operating mode:
Run-up
Standby/Vent
Evacuate
Measuring
Calibrating
Error / Warnings /
Maintenance messages
LED, green
Flashes
On
On
On
Flashes synchronously
Off
LED, yellow
Flashes
Off
Flashes slowly
On
Flashes synchronously
Flashes fast
