RS232
The Modul1000 is controlled via RS232 interface by an external computer. In this
mode, the Modul1000 cannot be controlled via the keyboard.
All
Control interfaces PLC, RS232 and Local
Local and PLC
The Modul1000 is controlled via the START, STOP and ZERO buttons on the device
and via the digital inputs.
Local and RS232
The Modul1000 is controlled via the START, STOP and ZERO buttons on the device
and via the digital inputs.
Local
The Modul1000 is controlled via the START, STOP and ZEROR buttons.
Main menu Settings
Local
Without request, the leak detector continuously sends the status and the leak rate.
Binary
Allows reading of equipment parameters, e.g. during maintenance.
UL2xxLeak Ware
Allows controlling and reading of measured values when connected to a computer.
(For operation of the Leak Ware refer to the corresponding operating instructions).
Notice:
ASCII
Enables the operation of the Modul1000 via an RS232 terminal. For further details
refer to Interface Description.
Main Menu Settings
In Commander mode, the Modul1000 has to be connected to an external pressure
gauge. In the "External pressure gauge" mode is for setting the characteristics and
the zero-point, as well as full scale of the used pressure gauge.
Characteristics:The following characteristics can be set: current linear, voltage
Interfaces RS232
The calibration function of the Leak Ware cannot be used for the
Modul1000. Please execute the function „STORE DATE" in the operating
mode „Single Part Measurement" for recording the measured values.
Interfaces External Pressure Gauge
linear, current logarithmic, voltage logarithmic.
