No. Displayed Message
Parameters are initialized in the
W87 I•STICK! Please check the
settings!
Parameters are lost in the
I•STICK! Please check the
W88
settings!
E89 Monitoring voltage F1,F2
E90 Monitoring voltage F1,F2
W91 P_ext smaller than p_A
Evacuation of sample takes too
W92
long .
Filling of the test sample with
W93
test gas takes too long.
W94 Time to "Ultra" too long
Discharge of test gas takes too
W95
long.
10-8
Error Messages and Warnings
Description and possible solutions
Missing or changed parameters in the I•STICK and new software version number
were detected.
A software update was performed and one or more new parameters were
detected. In this case, the message can be acknowledged. The parameter(s) were
automatically added.
Defective or missing parameter detected in the I•STICK. The software version
number did not change.
If the warning occurs after restart again, the I•STICK cannot be written on the
wiring backplane or is defect. I•STICK on wiring backplane is defective!
The write access was interrupted. Check the settings and acknowledge the error
message.
Voltage monitoring for fuses F1, F2 AD 24 B < 5,6 V.
Fuse F1 interface board (SSK) defective.
Voltage monitoring for fuses F1, F2 AD 24 B < 7.8 V.
Fuse F2 interface board (SSK) defective.
Pressure in the sample drops below the value of p_A, although only the test
chamber was pumped.
Sample was leaky.
Adaptation sample was leaky.
Wrong setting for p_A.
Time t1 > as the set evacuation time t_A.
Valve V30 does not open.
Fore pump defective
Test sample was leaky.
Wrong time setting for t_A.
Wrong setting for the evacuation pressure p_B.
Time t1 > as the set filling time for the sample t_C.
Valve test gas inlet V33 does not open.
Selected time for test gas inlet t_C too short.
Selected Test gas filling pressure p_C to high.
Time t2 >than the time t_F to reach the measuring mode „Ultra".
Test chamber leaky!
Sample is leaky.
Wrong setting for time t_F (time until ready for measurement "Ultra").
Time t1 > as the depressurizing time t_D.
Test gas pump system defect.
Valve V32 does not open.
The selected time t_D for reaching the depressurizing pressure p_D too short.
Selection of depressurizing pressure p_D wrong. Depressurizing pressure p_D >
set end pressure after the depressurizing time t_D has expired.
