Inficon Modul1000 Operating Manual page 105

+24V, 0.8 A
GND 24V
Fig. 9-7 External sensor supply 24 V with electrically isolated installation of mass
The voltage difference between pin 2 and the pins 4 and 5 is maximum ± 4 V.
Connection of sensors with
0 ... 10V signal
Notice:
+24V, 0.8 A
GND 24V
Input 1
GND 1
Input 2
GND 2
Fig. 9-8 Connection with common mass
1
2
3
Input 1
4
GND 1
5
Input 2
6
GND 2
Arrange the jumpers on the interface boards accordingly.
1
2
3
4
5
6
4 ... 20 mA
+
24V
-
Technical Data
9-17
