7.7

Fuse replacement

7.7.1

Overview on Electrical Fuses

7-10
Maintenance tasks
Mains switch housing chassis:
Designation Technical data Fuse for
Mains switch 2 x T 6.3 A
Wiring plane:
Designation Technical data Fuse for
F10 T 6,3 A
F11 T 0,8 A
Power supply unit ZWS240PAF-24/TA:
Designation Technical data Fuse for
F1 F 6.3 A
I/O PCB:
Designation Technical data Fuse for
F1; F2 T 0,8 A
F3 T 0,315 A
Circuit board MSV:
Designation Technical data Fuse for
F1 T 2 A
F2 T 3,15 A
F3 T 1 A
F4 M 0.032 A
Interface board:
Designation Technical data
F1 T 1 A
F2 T 0,8 A
F3 T 0,8 A
F4 T 1,6 A
F5 T 1,0 A
F6 T 1,0 A
Please note that this work is only performed by skilled electricians, since
Notice:
generally a cover of an electric module may have to be opened.
Power supply unit fuse (2-phase OFF)
Power supply unit TC 600
Fans
Fuse power supply unit
not used
not used
24 V main fuse for MSV card
Anode heater (no use)
15 V; +5V DC/DC transformer
Anode- cathode voltage (85 V)
24 V CONTROL UNIT
24 V REMOTE CONTROL; PC RS232
24 V PRESSURE GAUGE, PLC IN
24 V PLC OUT; VALVES; ACESSORIES
VALVES V30...V33 supply voltage (max.
30 V)
VALVES V34...V37 supply voltage (max.
30 V)
