4.2

Electrical installation

4.2.1

Mains socket

4.2.2

Electrical interfaces

Valves
4-2
Installation
The device is connected to the power system via the delivered power cable. Please
find the respective socket on the back of the device. (refer to
Caution
Place the device in a way that you can always reach the power plug.
All electrical interfaces of the Modul1000 are clearly visible arranged in a connecting
area on the right side of the device (refer to
Fig. 4-1 Electrical interfaces
The connection VALVES is for controlling external valves.
Fig.
Fig. 3-2).
Connectors:
LED yellow, LED green, CONTROL UNIT
(PC) RS232, REMOTE CONTROL
PLC IN / AUDIO
PLC OUT
RECORDER, PRESSURE GAUGE
ACCESSORIES
VALVES,
3-2/9).
